GE IC600PM500L Power Supply

This unit provides stable DC power to the backplane and all connected modules. The GE IC600PM500L converts AC line voltage into regulated 5 V and 24 V outputs. It measures 305 mm in width and 160 mm in height. This unit weighs approximately 2.8 kg for secure rack mounting.

Technical Specifications Table

Parameter	Value
Product Model	GE IC600PM500L
Brand	GE Fanuc
Category	Power Supply Module
Compatible Racks	GE Series Six
Input Voltage	120/230 V AC (switchable via jumper)
Input Frequency	50/60 Hz
Output Voltage 1	5 V DC
Output Current 1	15 A
Output Voltage 2	24 V DC
Output Current 2	2 A
Total Output Power	123 W maximum
Dimensions (W x H x D)	305 mm x 160 mm x 140 mm
Weight	2.8 kg
Connection Type	1 x screw terminal block (rear)
Internal Components	1 x transformer, 1 x rectifier bridge, 8 x filtering capacitors
Energy Storage	8 x 4700 µF electrolytic capacitors (total 37600 µF)
Hold-up Time	30 ms at full load
Efficiency	80% typical
Protection Features	Short circuit, overload, overvoltage, overtemperature

Internal Design and Power Distribution

This power supply uses a large step-down transformer with dual secondary windings. A full-bridge rectifier converts AC to DC for both output rails. The GE IC600PM500L employs eight large filtering capacitors for substantial energy storage. These capacitors provide 30 ms of hold-up time during short power interruptions. The 5 V DC output powers the backplane and all logic modules. The 24 V DC output supplies sensor power and relay circuits separately. An internal cooling fan maintains safe operating temperatures under full load.

Installation and Connection Guide

First, mount this power supply into the leftmost slot of your Series Six rack. Next, select the correct input voltage using the internal jumper (120 V or 230 V). Then, connect your AC mains wires to the L, N, and PE terminals on the rear block. Wire the 5 V output to your backplane distribution points for logic power. Use the 24 V output for field devices like sensors and relays. The module includes green LEDs for output status monitoring and a red LED for fault indication. This unit works with all GE Series Six racks and CPU models. Replace the unit immediately if the cooling fan fails or unusual noise occurs.
