GE IC693MDL930D Relay Output Module

This module switches high-power AC and DC loads using electromechanical relays. The GE IC693MDL930D provides 12 isolated outputs for industrial control applications. It measures 125 mm in width and 110 mm in height. This unit weighs approximately 0.35 kg for rack mounting.

Technical Specifications Table

Parameter	Value
Product Model	GE IC693MDL930D
Brand	GE Fanuc / Emerson
Category	Relay Output Module
Number of Outputs	12 channels
Output Type	Electromechanical relay, Form A (SPST-NO)
Output Voltage Range	5 V DC to 250 V DC / 24 V AC to 250 V AC
Output Current	2 A per channel (resistive)
Maximum Inrush Current	15 A for 10 ms
Contact Resistance	100 mΩ maximum
Dimensions (W x H x D)	125 mm x 110 mm x 55 mm
Weight	0.35 kg
Connector Type	1 x 24-pin female (terminal block)
Internal Components	12 x relays, 1 x suppression diode array
Electrical Isolation	1500 V AC between coil and contacts
Energy Storage	None (relays reset on power loss)
Switching Speed	10 ms maximum (operate + release)
Mechanical Life	10,000,000 operations
Electrical Life	100,000 operations at rated load
Operating Voltage	5 V DC (logic side from backplane)

Internal Design and Relay Construction

This output module uses twelve independent electromechanical relays on one board. Each relay provides a single-pole, single-throw normally-open contact. The GE IC693MDL930D includes a suppression diode array for inductive load protection. The module stores no energy for output retention after power-off. Consequently, all relays return to their normally-open state when the system loses power. Green LEDs on the front panel indicate the real-time status of each output channel.

Installation and Wiring Guide

First, mount this module into any Series 90-30 rack slot. Next, connect your load wires to the 24-pin terminal block using a flathead screwdriver. Then, wire the common terminals (C1, C2, C3) to your load return path. Each group of four outputs shares a common terminal. Use external fuses for short circuit protection on high-current loads. The module requires no external power supply for the relay coils. This unit works with all GE Series 90-30 CPU models including 311, 331, 341, and 363. Always install a suppression diode across inductive DC loads for longer relay life.
