GE QPI-2D100-E2P Touch Panel | 10.4" TFT, 800x600

This touch panel screen provides a reliable operator interface for industrial machines. It displays process data and accepts user commands through finger touch. You can mount this unit on a machine control cabinet door. The panel connects directly to PLCs via serial or Ethernet communication.

Technical Specifications & Key Parameters

Parameter	Detail
Product Model	GE QPI-2D100-E2P
Category	Touch Panel Screen (HMI)
Screen Size	10.4 inches diagonal
Display Type	TFT LCD with LED backlight
Resolution	800 x 600 pixels (SVGA)
Touch Technology	Resistive 4-wire analog
Weight	1.95 kg (4.3 lbs)
External Dimensions (W x H x D)	280 mm x 210 mm x 55 mm
Backlight Lifetime	50,000 hours typical
Energy Storage	470 µF capacitor (retains brightness settings for 10 seconds)
Communication Ports	One RS-232, one RS-422, one RS-485, one Ethernet 10/100
USB Ports	Two USB 2.0 host ports
Operating Voltage	24 V DC nominal (18–32 V DC range)
Current Draw	0.65 A at 24 V DC

Detailed Feature Overview

GE QPI-2D100-E2P features a 10.4-inch TFT LCD with 800 x 600 resolution. This display shows sharp graphics and small text clearly. The resistive touch layer responds to gloved fingers or stylus pens. A 50,000-hour LED backlight eliminates routine lamp replacements.

The unit draws only 0.65 A from a 24 V DC supply. Its 470 µF capacitor stores enough energy for brief power dips. This feature retains brightness and contrast settings for 10 seconds. Consequently, the screen returns to its previous state after a short interruption.

Connectivity and Data Exchange

Four communication ports provide flexible PLC connections. Use RS-232 for point-to-point programming or RS-485 for multi-drop networks. The Ethernet port supports web-based monitoring and remote access. Two USB host ports allow data logging to flash drives. You can also upload screen designs without opening the enclosure.

Mechanical Installation

The panel measures 280 mm wide by 210 mm high. Its 55 mm depth fits standard 60 mm deep enclosures. Four mounting clips secure the unit from the front side. The included gasket creates a NEMA 4X seal against moisture. Operating temperature ranges from 0°C to 50°C without external cooling.
