Schneider TSXPSY8500 Power Supply

This module provides regulated DC power for Schneider Modicon Premium PLC systems. It converts 115 or 230 VAC input into stable 5 and 24 VDC outputs. Therefore, it supplies all connected I/O modules and the CPU with clean operating voltage.

Technical Specifications of Schneider TSXPSY8500

Parameter	Specification
Brand	Schneider Electric
Full Model	TSXPSY8500
Category	Power Supply Module
Dimensions (L x W x H)	13.5 cm x 10.0 cm x 8.5 cm (5.31″ x 3.94″ x 3.35″)
Module Weight	0.65 kg (1.43 lbs)
Input Voltage Range (AC)	85 to 265 VAC (Universal)
Input Frequency	47 to 63 Hz
Input Current (115 VAC)	1.2 A (Maximum)
Input Current (230 VAC)	0.6 A (Maximum)
Inrush Current	15 A Peak (Cold Start at 115 VAC)
Output Voltage 1	+5 VDC (Regulated)
Output Current 1	3.0 A (Continuous)
Output Voltage 2	+24 VDC (Regulated)
Output Current 2	1.5 A (Continuous)
Output Ripple (5 VDC)	< 50 mV Peak-to-Peak
Output Ripple (24 VDC)	< 100 mV Peak-to-Peak
Output Accuracy (5 VDC)	±2% (No Load to Full Load)
Output Accuracy (24 VDC)	±3% (No Load to Full Load)
Hold-Up Time	20 ms at Full Load (115 VAC Input)
Efficiency	> 80% (Typical at 115 VAC)
Overvoltage Protection	Yes (5 VDC: 5.8 V, 24 VDC: 28 V)
Overcurrent Protection	Yes (Automatic Foldback + Hiccup Mode)
Short Circuit Protection	Yes (Continuous Recovery)
Overtemperature Protection	Yes (Shutdown at 95°C Internal)
On-Board Components	1 Switching Transformer + 1 Bridge Rectifier + 4 Filter Capacitors + 1 PWM Controller IC + 2 Optocouplers + 4 Protection Diodes + 1 Fuse (Internal)
Energy Storage	2 x 1000 µF Electrolytic Capacitors (450V, Input) + 2 x 2200 µF Electrolytic (16V, 5V Output) + 1 x 1000 µF Electrolytic (35V, 24V Output)
Operating Temperature	0°C to +55°C (32°F to 131°F)
Storage Temperature	-25°C to +85°C (-13°F to 185°F)
Cooling	Passive (Natural Convection)
Mounting Type	Premium PLC Rack (Leftmost Slot)
Status Indicators	1 Green LED (5 VDC OK) + 1 Green LED (24 VDC OK) + 1 Red LED (Fault)

Energy Storage and Hold-Up Performance

The Schneider TSXPSY8500 stores significant energy using five large electrolytic capacitors. Two input capacitors store energy from the AC line for 20 ms hold-up time. Two output capacitors filter the 5 VDC supply for stable backplane power. One capacitor filters the 24 VDC output for I/O modules. Consequently, the system continues running through brief AC power interruptions.

Protection Features and Safety

This power supply includes comprehensive protection for all output circuits. Overvoltage protection shuts down the supply if voltages exceed safe limits. Overcurrent protection reduces output current automatically during overload conditions. Short circuit protection allows continuous recovery without permanent damage. Thus, the Schneider TSXPSY8500 safeguards your entire PLC system.

Installation and Status Indication

You will find three LED indicators on the module’s front panel. A green 5V OK LED lights when the 5 VDC output is within specification. A green 24V OK LED indicates proper 24 VDC output voltage. A red Fault LED illuminates during overcurrent or overtemperature events. The module occupies the leftmost slot of the Premium rack. Therefore, it powers all CPU and I/O modules through the backplane.
