GE A16B-2201-0800/02A Vision Module

This vision engine module processes image data for part inspection and tool monitoring. It interfaces directly with the CNC controller for real-time quality control. You can install this board into any standard GE CNC rack slot. The unit suits automated gauging, surface inspection, and alignment applications.

Technical Specifications & Key Parameters

Parameter	Detail
Product Model	GE A16B-2201-0800/02A
Category	Vision Engine Module
Dimensions (L x W)	260 mm x 200 mm
Weight	0.52 kg (1.15 lbs)
Processor Type	Dedicated image processor with DSP
Clock Speed	66 MHz
Frame Buffer Memory	8 MB SDRAM (stores up to 16 images)
Program Memory	2 MB Flash (stores inspection routines)
Component Count	94 ICs, 76 capacitors, 118 resistors
Energy Storage	1500 µF total capacitance (holds buffer for 8 ms)
Video Input Interface	One 26-pin header (composite or S-video)
Trigger Inputs	Two opto-isolated trigger inputs (24 V DC)
Output Signals	Pass/fail relay output and strobe control
Operating Voltage	5V DC and ±15V DC from backplane
Current Draw	1.3 A at 5V DC, 0.2 A at ±15V DC
Status LEDs	Power, active, trigger, pass, fail

Detailed Feature Overview

GE A16B-2201-0800/02A uses a 66 MHz DSP for high-speed image processing. This processor analyzes each frame in under 10 milliseconds. The module stores up to 16 images in its 8 MB frame buffer. Consequently, it can compare current parts against reference images quickly.

Two opto-isolated trigger inputs start inspections automatically. These inputs accept 24 V DC signals from part presence sensors. A built-in pass/fail relay output connects to sorting mechanisms or alarms. An additional strobe output controls external lighting for consistent image quality. A 1500 µF capacitor holds frame buffer data for 8 milliseconds during power dips.

Memory and Image Processing

The 8 MB SDRAM stores multiple inspection images simultaneously. This buffer allows side-by-side comparison of good and bad parts. The 2 MB Flash memory retains up to 50 inspection routines permanently. You can upload new routines via the CNC backplane without removing the board. Ninety-four integrated circuits handle image acquisition, processing, and communication.
