Schneider DAO 013 | Digital Output Module 24V DC 8 Channels

The DAO 013 controls DC loads like solenoids, relays, and indicator lights. This digital output module provides eight independent channels for field actuation. It mounts directly into any standard Modicon PLC rack slot. Consequently, you can drive multiple devices from a single module location.

You can rely on this module for fast and reliable output switching. The DAO 013 uses solid-state transistor technology for silent operation. Each channel includes built-in short-circuit and overload protection circuits. Therefore, this module safeguards your PLC from field wiring faults.

Output Specifications and Channel Details

The module delivers 0.5 amps per channel at 24V DC nominal voltage. Each output on the DAO 013 switches independently without interaction between channels. A common return terminal serves all eight outputs for simplified wiring. The module responds to logic commands within 0.5 milliseconds typically.

Outputs feature automatic thermal shutdown during excessive current conditions. The DAO 013 recovers automatically when the temperature normalizes. An LED indicator on the front panel shows each channel’s active state. Below is a complete breakdown of its technical characteristics.

Specification	Detail
Number of Outputs	8 (Solid-state transistor)
Output Type	Sourcing (PNP)
Output Voltage	24V DC nominal (10 to 30V DC)
Output Current per Channel	0.5 A (Maximum)
Total Output Current	4 A (Maximum, all channels)
Output Response Time	0.5 ms (Typical)
Protection Features	Short-circuit, overload, thermal
Leakage Current (OFF)	< 0.1 mA
Voltage Drop (ON)	< 1.5V at 0.5A
Dimensions (W x H x D)	40 mm x 130 mm x 120 mm
Weight	0.25 kg (250 grams)
Power Draw (5V)	100 mA
Power Draw (24V load)	Depends on connected loads
Energy Storage	None (No battery or capacitor)

Interface and Field Wiring Connections

A removable screw terminal block accepts all output field wiring. The DAO 013 uses 20-pin connector for secure signal termination. Each terminal accepts wire sizes from 0.2 to 2.5 mm². Green LEDs illuminate when the corresponding output remains active.

You must supply external 24V DC power to the common terminal. The DAO 013 does not generate output power from the backplane alone. A separate fuse protects the entire output group from major faults. Therefore, installation requires attention to proper power supply connections.

Operational Benefits for Control Applications

This output module drives small inductive loads without external suppression. The DAO 013 includes internal flyback diodes for each channel. It handles LED indicators, contactors, and small solenoids effectively. Engineers trust this module for reliable machine control in factory automation.
