Siemens 6GK1901-0AA00-0AC0 Transceiver

Technical Overview

The Siemens 6GK1901-0AA00-0AC0 is a SIMATIC NET transceiver designed for Industrial Ethernet applications . This module features two interfaces, enabling the connection of two terminals within an industrial Ethernet network . The Siemens 6GK1901-0AA00-0AC0 supports reliable data transfer in demanding industrial environments, making it a practical choice for integrating multiple Ethernet endpoints . It comes complete with a mounting plate, cover plate with terminator, two installation kits, and an installation guide for straightforward deployment .

This transceiver allows devices without a built-in industrial twisted-pair transceiver to connect to the network via an AUI interface . It supports a broad range of industrial protocols, ensuring compatibility with various control systems and devices .

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Model Number	6GK1901-0AA00-0AC0
Product Type	Industrial Ethernet Transceiver
Network Compatibility	Industrial Ethernet
Interface Type	Two interfaces
Data Transfer Rate	Up to 12 Mbit/s
Communication Protocol	PROFIBUS DP
Operating Voltage	24 VDC
Power Consumption	5W (Max.)
Operating Temperature	-25°C to +60°C
Storage Temperature	-40°C to +85°C
Protection Class	IP20
Connector Type	RS-485
Mounting Type	Panel-mount with hardware included
Weight	0.4 kg
Certifications	CE, UL, FCC
Country of Origin	Germany

Key Features

Dual Interface Connectivity – The Siemens 6GK1901-0AA00-0AC0 provides two interfaces, allowing flexible connection of terminals in industrial Ethernet networks .

Industrial-Grade Reliability – This transceiver operates reliably in harsh industrial environments with a wide temperature range from -25°C to +60°C .

High-Speed Data Transfer – The module supports communication speeds up to 12 Mbit/s, ensuring fast data processing for real-time control applications .

Complete Mounting Kit – The package includes a mounting plate, cover plate with terminator, two installation kits, and an installation guide for easy deployment .

AUI Interface Compatibility – This transceiver enables connection of devices without built-in twisted-pair transceivers to the industrial Ethernet network .

IP20 Protection – The module offers protection against solid objects, suitable for installation in control cabinets .

Applications

The Siemens 6GK1901-0AA00-0AC0 suits various industrial automation applications requiring robust Ethernet connectivity. It excels in factory automation systems, process control networks, and distributed control architectures . The module is also ideal for integrating legacy devices into modern Industrial Ethernet networks via AUI interfaces .
