Technical Overview
The Siemens 6AV3688-4CX07-0AA0 is a push button panel for industrial control and monitoring applications. This panel provides a robust operator interface with illuminated push buttons and indicator lamps for machine control. It features 8 configurable push buttons with integrated LEDs for status feedback. Moreover, the 6AV3688-4CX07-0AA0 connects to PLCs via PROFIBUS DP, enabling seamless integration into automation systems. This panel offers a durable solution for manual control in demanding industrial environments.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 6AV3688-4CX07-0AA0 |
| Product Type | Push Button Panel |
| Communication Interface | PROFIBUS DP |
| Number of Push Buttons | 8 illuminated buttons |
| Button Color | Configurable (yellow, red, green, blue) |
| Indicators | Integrated LEDs per button |
| Actuation Type | Momentary or latching (configurable) |
| Protection Rating | IP65 (front panel) |
| Mounting | Panel mount with sealing frame |
| Power Supply | 24 V DC |
| Power Consumption | 10 W typical |
| Operating Temperature | 0°C to 50°C |
| Dimensions (W × H × D) | 240 mm × 120 mm × 45 mm |
| Weight | Approximately 1.5 kg |
Performance and Application Benefits
The 6AV3688-4CX07-0AA0 offers a reliable and intuitive operator interface for manual machine control. Moreover, the eight illuminated push buttons provide clear status feedback, enabling operators to identify active functions at a glance. In addition, the PROFIBUS DP interface ensures fast and reliable communication with the PLC, supporting real-time control updates. Consequently, the IP65 front panel withstands water, dust, and oil exposure, ensuring durability in harsh industrial settings. Furthermore, the panel supports configurable button functions, allowing users to tailor the interface to specific application requirements. Therefore, this push button panel is ideal for machine control stations, conveyor systems, and packaging equipment requiring robust operator input.
