Schneider ASB875001 Analog Input Module

Product Overview

The ASB875001 converts field sensor signals into digital data for PLC systems. You will find this module in factory automation and process control panels. It accepts both voltage and current inputs from transducers. Additionally, this module provides per-channel software configurability for maximum flexibility. Therefore, you can mix sensor types on the same unit.

Technical Specifications

The table below lists all key parameters for this analog input module.

Parameter	Value / Description
Full Model	ASB875001
Category	Analog Input Module
Dimensions (W x H x D)	25.4 cm x 11.2 cm x 6.0 cm (10.0 in x 4.41 in x 2.36 in)
Weight	0.35 kg (0.77 lb)
Analog Inputs	8 differential channels
Input Ranges	0-10V, ±10V, 0-20mA, 4-20mA (software selectable)
Main Connector	One 18-pin removable terminal block
Onboard Components	16 resistors, 12 capacitors, 8 op-amps, 1 ADC
Energy Storage	None (no capacitors above 1 µF)
Operating Voltage	24V DC ±20%
Current Draw	0.12 A maximum
Resolution	14-bit (16,384 counts)
Accuracy	±0.1% of full scale at 25°C
Conversion Time	10 ms for all 8 channels
Update Rate	100 Hz per channel
Mounting	DIN rail (35 mm) with clip

The ASB875001 stores absolutely no energy onboard. Therefore, you can handle this module immediately after power removal. Use the removable terminal block for all field wiring connections. Meanwhile, the software selects each input range independently.

Installation and Compatibility

You can mount this module on any standard 35 mm DIN rail. Snap the ASB875001 firmly onto the rail until you hear the click. Then connect the 24V supply to terminals 1 and 2. Always configure the input ranges before you apply process signals.

This module communicates via the Advantys backplane bus. It automatically detects the slot position on power-up. The ASB875001 replaces older ASB870 series modules directly without rewiring.

Environmental and Safety Data

The ASB875001 operates from -10°C to +55°C. It withstands 3g vibration per IEC 60068-2-6. The circuit board has a full conformal coating for humidity protection. Consequently, you can use this module in wash-down environments. Avoid connecting voltages above 30V to any input channel.
