ABB Bailey IIPRT11 Fiber Optic Cable

Cable Overview

This fiber optic cable connects Bailey INFI 90 system components over long distances. You can install ABB Bailey IIPRT11 between controller modules and remote I/O stations. The cable transmits data using light signals instead of electrical current. It provides complete electrical isolation between connected devices.

Technical Specifications

Parameter	Value
Cable length	11 meters (standard)
Cable diameter	3.5 mm outer jacket
Fiber type	Multimode 62.5/125 µm
Connector type	ST (straight tip) male on both ends
Maximum bend radius	50 mm (dynamic), 30 mm (static)
Attenuation	3.0 dB/km maximum at 850 nm
Bandwidth	200 MHz·km at 850 nm
Wavelength	850 nm (typical)
Operating temperature	-20°C to +70°C
Tensile strength	100 N maximum
Jacket material	PVC (low smoke, zero halogen)
Color	Orange (standard multimode)
Total components	1 cable assembly with 2 connectors
Energy storage	None (passive transmission medium)

Cable Construction and Materials

The cable contains a glass fiber core surrounded by cladding material. A Kevlar strength member provides pull resistance during installation. Moreover, the PVC jacket protects against abrasion and chemicals. ST connectors lock securely with a bayonet-style coupling mechanism. Consequently, vibration does not disconnect the optical link accidentally.

Installation Process

You can route ABB Bailey IIPRT11 between INFI 90 modules within the same cabinet. The ST connectors push and twist into compatible fiber optic ports. Furthermore, the cable bends around corners with a 50 mm minimum radius. The orange jacket color also identifies it as a multimode fiber easily.

Performance Advantages

This cable transmits data at speeds up to 10 Mbps over 11 meters. The optical medium provides complete galvanic isolation between connected devices. Therefore, ground loops and lightning surges do not affect data transmission. The Kevlar strength member also prevents breakage during cable tray pulls.

Safety and Compliance

ABB Bailey IIPRT11 meets CE, UL, and RoHS standards. The cable stores no electrical energy that could create shock hazards. Hence, technicians can handle and disconnect the cable safely at any time.
