GE QPI-2D100-S2P Touch Screen

This industrial touch screen provides intuitive operator interface for factory automation systems. The GE QPI-2D100-S2P features a 10.4-inch diagonal display with projected capacitive touch technology. The screen supports multi-touch gestures for zooming and scrolling operations. Consequently, operators can navigate complex HMI screens with minimal training.

Technical Specifications of the Touch Screen

The GE QPI-2D100-S2P measures 280 mm in width and 210 mm in height. Its depth reaches 45 mm for easy panel mounting into standard cutouts. The unit weighs approximately 2.1 kg including the metal mounting brackets. A single front bezel houses seven programmable function keys for quick access. The rear panel provides one DVI-D video port and two USB 2.0 interfaces. This design stores no energy beyond minimal capacitive touch sensing. Therefore, the screen contains no batteries or energy storage capacitors.

Parameter	Specification
Brand	GE
Full Model	QPI-2D100-S2P
Category	Industrial Touch Screen
Dimensions (W x H x D)	280 mm x 210 mm x 45 mm
Weight	Approximately 2.1 kg
Screen Size	10.4 inches diagonal
Display Resolution	1024 x 768 pixels (XGA)
Touch Technology	Projected capacitive, multi-touch
Function Keys	7 programmable keys
Video Interface	1 x DVI-D
USB Ports	2 x USB 2.0
Energy Storage	None (sensing only)
Supply Voltage	24V DC at 0.8 A typical

Functional Features and Display Quality

The GE QPI-2D100-S2P delivers 350 cd/m² brightness for clear viewing in bright environments. You can adjust the LED backlight intensity through software commands. The screen supports glove-friendly touch operation for industrial safety requirements. An optically bonded panel reduces glare and improves outdoor readability. Consequently, operators receive excellent visibility even under harsh lighting conditions.

Installation and Connectivity

You must mount this touch screen into a standard 10.4-inch panel cutout. The GE QPI-2D100-S2P requires four screws for secure front-panel attachment. A DVI-D cable connects the screen to any compatible industrial computer. Two USB ports provide touch data and peripheral connection simultaneously. Always verify cable lengths before final panel installation.

Maintenance and Operational Benefits

Because the GE QPI-2D100-S2P stores no battery-backed data, it requires no periodic battery changes. The sealed front bezel meets IP65 rating for dust and water resistance. Technicians can clean the glass surface with standard industrial cleaning agents. Consequently, the touch screen offers reliable service in food processing and chemical plants.
