GE IC693MDL740J DC Output Module

This DC output module provides reliable discrete control for Series 90-30 PLC systems. The GE IC693MDL740J features twelve independent output channels in a single-wide form factor. Each channel delivers 24V DC at 1.0A for driving solenoids and contactors. Consequently, automation engineers can control medium-power field devices with confidence.

Technical Specifications of the DC Output Module

The GE IC693MDL740J fits standard Series 90-30 PLC racks without any adapter. Its height measures 110 mm, and its depth reaches 130 mm. The module weighs approximately 0.31 kg including all internal circuitry. A single front panel LED array shows the on-off status for each output channel. The rear side uses a 48-pin backplane connector for power and communication. This design stores minimal energy in small suppression components only. Therefore, the module contains no batteries or large capacitors.

Parameter	Specification
Brand	GE Fanuc
Full Model	IC693MDL740J
Category	DC Output Module
Dimensions (H x D)	110 mm x 130 mm
Weight	Approximately 0.31 kg
Output Channels	12 independent outputs
Output Type	24V DC, sourcing
Output Current	1.0A per channel, 4A total per common
Response Time	1ms typical off to on, 1ms on to off
Backplane Connector	48-pin
Energy Storage	Minimal (suppression only)
Supply Voltage	5V DC from backplane

Functional Features and Protection Circuits

The GE IC693MDL740J includes built-in thermal shutdown per output channel group. You can connect each output directly to inductive loads without external suppression. The module automatically limits current during overload or short circuit conditions. Each output also features a green LED indicator for visual troubleshooting. Consequently, maintenance teams can identify faulty circuits instantly without meters.

Installation and System Compatibility

You must install this DC output module into any Series 90-30 PLC rack slot. The GE IC693MDL740J requires a standard 5V DC supply from the backplane. A removable terminal block accepts field wiring from 14 to 22 AWG. The module supports hot insertion into powered racks without system shutdown. Always verify load current limits before connecting multiple devices to one common.

Maintenance and Operational Benefits

Because the GE IC693MDL740J stores no battery-backed data, it requires no periodic battery changes. Technicians can replace the module without losing any configuration settings. The transparent terminal cover prevents accidental contact with live wires. Consequently, the module offers safe and simple maintenance for industrial control panels.
