GE IC693CMM311F Communications Module

This communications control module manages serial data exchange for GE Fanuc Series 90-30 PLCs. It provides two independent ports for connecting to external devices. You can configure this unit for various industrial protocols.

Technical Specifications

Parameter	Details
Brand	GE Fanuc
Model	GE IC693CMM311F
Category	Communications Control Module (Series 90-30)
Dimensions (H x W x D)	115 mm x 32 mm x 140 mm
Weight	0.22 kg
Number of Ports	2 isolated serial ports
Port 1 Interface	RS-232 (15-pin D-sub)
Port 2 Interface	RS-232 (15-pin D-sub) or RS-485 (selectable)
Data Rate Range	300 bit/s to 19.2 kbit/s (each port independently)
Supported Protocols	SNP, SNP-X, RTU, CCITT #16
Internal Buffer	4 KB RAM for transmit and receive queues
Number of Internal Components	1 CPU + 2 UARTs + 1 buffer memory + 1 PCB
Maximum Cable Length (RS-232)	15 meters
Maximum Cable Length (RS-485)	1200 meters
Power Supply	5 V DC from backplane only
Current Draw (5V)	280 mA typical
Built-in Energy Storage	220 µF capacitor for buffer retention
Status Indicators	4 LEDs (OK, PORT1 ACT, PORT2 ACT, FAULT)
Isolation Voltage	500 V AC between ports and backplane
Operating Temperature	0°C to 60°C
Humidity Tolerance	5% to 95% non-condensing

Detailed Feature Overview

This module features two fully independent serial communication ports. Each port supports different baud rates and protocols simultaneously. The 4 KB buffer handles data queues without interrupting the PLC scan.

A 220 µF capacitor retains the buffer during brief power interruptions. Consequently, you avoid losing partially transmitted messages during brownouts. Port 2 offers selectable RS-232 or RS-485 for long-distance connections.

You will find four status LEDs on the front panel. These LEDs indicate module health and activity on both ports. The RS-485 interface supports distances up to 1200 meters for remote device networking.

Installation and Compatibility

GE IC693CMM311F fits any slot in a Series 90-30 baseplate. Use configuration software to set baud rates and protocols per port. Connect shielded cables for RS-485 networks to reduce electrical noise.
