GE A02B-0168-B012 Single Channel Servo Amplifier

This amplifier drives one AC servo motor for precision motion control. The GE A02B-0168-B012 provides high-performance torque and speed regulation for industrial axes. It measures 220 mm in width and 180 mm in height. This unit weighs approximately 2.1 kg for cabinet mounting.

Technical Specifications Table

Parameter	Value
Product Model	GE A02B-0168-B012
Brand	GE Fanuc / General Electric
Category	Single Channel Servo Amplifier
Number of Axes	1
Input Voltage	200-230 V AC, 3-phase
Input Frequency	50/60 Hz
Rated Output Current	12 A RMS
Peak Output Current	24 A (for 2 seconds)
Control Method	Sinusoidal PWM with vector control
Dimensions (W x H x D)	220 mm x 180 mm x 170 mm
Weight	2.1 kg
Communication Interface	1 x FANUC serial servo bus
Encoder Interface	1 x incremental encoder (2500 PPR)
Control Inputs	4 x optically isolated (24 V DC)
Control Outputs	2 x relay (24 V DC, 1 A)
Internal Components	1 x IGBT module, 1 x DSP, 3 x current sensors
Energy Storage	2 x 1500 µF DC bus capacitors
Regeneration	Built-in resistor (30 Ω, 50 W)
Protection Features	Overcurrent, overvoltage, overtemperature
Operating Temperature	0°C to 50°C

Internal Design and Servo Control

This servo amplifier uses a single IGBT module for motor drive. A DSP executes vector control algorithms at 16 kHz switching frequency. The GE A02B-0168-B012 accepts velocity and torque commands via the serial servo bus. Three current sensors provide real-time feedback for precise torque regulation. Two 1500 µF capacitors store energy for peak power demands. Consequently, this amplifier delivers smooth motion for single-axis applications.

Installation and Wiring Guide

First, mount this amplifier vertically inside a ventilated control cabinet. Next, connect 3-phase AC power to the L1, L2, and L3 terminals. Then, wire the servo motor cables to U, V, and W output terminals. Connect the encoder feedback cable to the CN2 port securely. Use shielded cables for all encoder and control signal wiring. The amplifier requires at least 100 mm clearance for proper air circulation. Four LED indicators show power, ready, run, and fault status. This amplifier works with GE Fanuc servo motors and CNC controllers. Always install an external circuit breaker for overcurrent protection.
