GE IC610CHS134A Baseplate | 4-Slot Chassis

This baseplate houses the CPU, power supply, and I/O modules securely. The GE IC610CHS134A provides 4 slots for Series One system components. It measures 280 mm in width and 120 mm in height. This unit weighs approximately 1.1 kg for panel mounting.

Technical Specifications Table

Parameter	Value
Product Model	GE IC610CHS134A
Brand	GE Fanuc
Category	Baseplate / Mounting Chassis
Compatible Series	GE Series One (IC610)
Number of Slots	4 slots
Slot Type	Series One standard
Backplane Bus	Passive with integrated PCB
Dimensions (W x H x D)	280 mm x 120 mm x 85 mm
Weight	1.1 kg
Mounting Type	Panel (4 x mounting holes)
Internal Components	1 x backplane PCB, 4 x slot connectors
Ground Connection	1 x M4 grounding stud
Energy Storage	None (passive backplane)
Operating Voltage	Supplied by power supply module
Operating Temperature	0°C to 60°C

Internal Design and Slot Configuration

This baseplate uses a passive backplane PCB for signal distribution. Four slot connectors link each module to the internal bus. The GE IC610CHS134A positions the power supply in the leftmost slot for proper layout. The CPU occupies the next slot for direct backplane control. Remaining two slots accept I/O modules as needed. The passive design introduces no signal delay or active termination. Consequently, this baseplate supports reliable communication for small control systems.

Installation and Module Placement Guide

First, mount this baseplate onto a panel using four M4 screws. Next, install the power supply module into the leftmost slot firmly. Then, insert your CPU module into the second slot from the left. Fill the remaining two slots with input or output modules as needed. Connect the ground terminal to your system’s earth ground for safety. This baseplate works with all Series One CPU models including IC610CPU101, IC610CPU104, and IC610CPU106. Always slide modules into the guide rails before pressing them onto the backplane connector.
