GE IC610CHS114A | Series Six Power Supply 115V AC 50W

The IC610CHS114A supplies regulated DC power to the Series Six rack. This power supply unit converts incoming 115V AC to stable DC voltages. It provides reliable energy for all backplane logic and I/O circuits. Consequently, your entire PLC system receives clean, consistent operating power.

You can mount this module in the leftmost slot of any Series Six rack. The IC610CHS114A accepts a nominal input of 115V AC at 50/60 Hz. It also includes overload protection and short-circuit current limiting features. Therefore, this unit safeguards your expensive PLC components from electrical faults.

Output Specifications and Power Capacity

The module delivers 5V DC at 10 amps for backplane logic circuits. The IC610CHS114A also provides 24V DC at 2 amps for field devices. Its total output power capacity reaches 50 watts under normal operation. A front-panel LED indicates when all outputs remain within specifications.

The power supply stores energy in a capacitor bank for ride-through. This energy storage maintains output during brief input voltage dips. The IC610CHS114A holds up the 5V rail for approximately 20 milliseconds. Below is a complete breakdown of its technical characteristics.

Specification	Detail
Product Type	Series Six Power Supply Module
Input Voltage	115V AC ±15% (47-63 Hz)
Output Voltage 1	5V DC at 10A (Backplane logic)
Output Voltage 2	24V DC at 2A (Field power)
Total Output Power	50W (Maximum)
Hold-up Time	20 ms (At full load)
Efficiency	75% (Nominal load)
Energy Storage	Electrolytic capacitor bank
Dimensions (W x H x D)	305 mm x 25 mm x 178 mm
Weight	3.5 kg (Approx.)
Input Protection	Fuse (User replaceable)
Cooling	Natural convection (No fan)

Interface Layout and Connection Points

The front panel features a 3-pin terminal block for AC input wiring. The IC610CHS114A includes a separate connector for DC output distribution. A green LED confirms normal operation of all output voltages. The module also provides a chassis grounding screw for safety.

This power supply connects to the backplane through a multi-pin header. The IC610CHS114A operates at 50 or 60 Hz without any adjustment. It requires no manual voltage selection for different input frequencies. Therefore, installation involves only connecting AC wires and rack mounting.

Operational Benefits for System Reliability

This power module protects your PLC during unstable grid conditions. The IC610CHS114A handles input voltage fluctuations without disrupting controller operation. Its built-in thermal protection shuts down during excessive temperature conditions. Engineers trust this unit for continuous 24/7 operation in legacy Series Six systems.
