Siemens 6ES7677-2VB42-0GB0 ET 200SP Open Controller

The Siemens 6ES7677-2VB42-0GB0 Open Controller combines a PC-based S7-1500 software controller with PC applications and optional visualization . This CPU 1515SP PC2 T model integrates control and computing in a single compact ET 200SP device . It includes a preinstalled Windows 10 IoT Enterprise 64-bit operating system .

Technical Specifications of Siemens 6ES7677-2VB42-0GB0

The Siemens 6ES7677-2VB42-0GB0 features 8 GB of RAM and a 30 GB CFast drive . It supports the S7-1500 Software Controller CPU 1505SP T with motion control capabilities . The module provides extensive networking interfaces for flexible connectivity. It operates in ambient temperatures from -20 °C to +60 °C .

Parameter	Specification
Model Number	Siemens 6ES7677-2VB42-0GB0
Product Type	CPU 1515SP PC2 T Open Controller
Product Family	SIMATIC ET 200SP
RAM	8 GB
Storage	30 GB CFast (Windows 10 IoT Enterprise 64-bit)
Software Controller	CPU 1505SP T preinstalled
Interfaces	1x PROFINET (via BusAdapter), 1x 10/100/1000 Mbps Ethernet, 2x USB 3.0, 2x USB 2.0, 1x DisplayPort
PROFINET Connections	88 max
Connectable IO Devices	128 max
Address Area (Inputs/Outputs)	8 kbyte each
Operating Temperature	-20 °C to +60 °C
Weight	Approx. 0.83 kg
BusAdapter Support	BA 2x RJ45, BA 2x FC, BA 2x SCRJ, BA SCRJ/RJ45, BA SCRJ/FC, BA 2x LC, BA LC/RJ45, BA LC/FC

Integration and Application

The Siemens mounts on a standard DIN rail and fits into the ET 200SP system architecture. This Open Controller supports PROFINET IO Controller and Device modes, as well as OPC UA communication . It includes motion control resources for up to 2,400 technology objects . You can deploy this controller for distributed automation tasks requiring both PC functionality and real-time control.
