Siemens 6ES7132-6BF00-0BA0 Digital Output Module for ET 200SP

The Siemens 6ES7132-6BF00-0BA0 digital output module adds eight 24 V DC output channels to the SIMATIC ET 200SP distributed I/O system. This standard module (DQ 8x24VDC/0.5A ST) drives actuators, relays, and indicator lamps with a 0.5 A current per channel. Its compact 15 mm width saves valuable space in control cabinets. The module connects to BaseUnit Type A0 and uses the CC02 color code for straightforward wiring identification.

Technical Specifications of Siemens 6ES7132-6BF00-0BA0

The Siemens 6ES7132-6BF00-0BA0 module delivers a rated output voltage of 24 V DC, operating within a valid range of 19.2 V to 28.8 V. Its source output (PNP switching) design provides a typical power loss of just 1 W. The module consumes a maximum of 35 mA when idle. It includes comprehensive module diagnostics that detect short circuits to L+ and ground, wire breaks, and supply voltage faults. The firmware version V1.1 supports I&M data functions.

Integration and Application

The Siemens 6ES7132-6BF00-0BA0 module plugs directly onto the BaseUnit Type A0 within the ET 200SP station. It supports hot-swapping for convenient maintenance without system downtime. The module’s diagnostic functions enable rapid fault identification and troubleshooting. You can deploy this digital output module for conveyor systems, packaging machinery, signaling systems, and general-purpose discrete control applications.
