Reliable Connectivity for S5 Systems
The 6ES5731-0CB00 provides a specific plug-in connecting cable for Siemens SIMATIC S5 automation systems. This cable links central controllers to remote I/O stations and peripheral devices reliably. It features a 15-pin D-sub connector on both ends. The cable uses high-quality materials for durable industrial connectivity. Consequently, it ensures secure data transmission between system components.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Siemens |
| Series | SIMATIC S5 |
| Category | Connecting Cable |
| Part Number | 6ES5731-0CB00 |
| Cable Length | 3 meters (approximately 9.8 feet) |
| Connector Type (Both Ends) | 15-pin D-sub (male) |
| Protocol Support | S5 remote I/O bus |
| Shielding | Fully shielded (foil + braid) |
| Outer Diameter | 8.0 mm |
| Conductor Gauge | 24 AWG (signal) |
| Jacket Material | PVC (oil-resistant, flexible) |
| Storage Temperature | -40°C to +80°C |
| Operating Temperature | -20°C to +70°C |
| Weight | 0.3 kg |
Mechanical Design and Durability
The 6ES5731-0CB00 incorporates robust overmolded strain relief boots on both connector ends. This design prevents conductor fatigue from repeated bending cycles. Gold-plated contacts ensure reliable signal integrity and corrosion resistance. Dual-layer shielding effectively rejects electromagnetic interference from surrounding equipment. The flexible PVC jacket withstands oils and chemicals commonly found in industrial environments.
Application and Integration
This cable connects S5 CPUs to remote I/O racks and distributed I/O stations. The 3-meter length provides sufficient reach for cabinet-to-cabinet connections. Users should avoid exceeding the total bus length of 100 meters when daisy-chaining.
