This digital input module captures field signals for SIMATIC S5 automation systems. It monitors 32 discrete sensors simultaneously without signal interference. You can install this unit in any standard S5 rack slot.
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Siemens |
| Model | Siemens 6ES5436-6AA11 |
| Category | Digital Input Module (SIMATIC S5 Series) |
| Dimensions (H x W x D) | 250 mm x 25 mm x 210 mm |
| Weight | 0.72 kg |
| Number of Inputs | 32 channels |
| Input Type | 24 V DC, sink/source compatible |
| Input Voltage Range | 20.4 V to 28.8 V DC |
| Input Current per Channel | 7 mA typical at 24 V DC |
| Signal 0 (Low) | -3 V to +5 V DC |
| Signal 1 (High) | 15 V to 30 V DC |
| Input Delay | 3 ms (configurable to 0.5 ms or 6 ms) |
| Internal Components | 32 optocouplers + 1 input filter array + 1 PCB assembly |
| Interface Type | 48-pin front connector (requires Siemens 6ES5497-4UB31) |
| Isolation | 500 V AC between channels and backplane |
| Number of Isolated Groups | 4 groups (8 inputs per group) |
| Power Supply | 5 V DC from backplane only |
| Current Draw (5V) | 180 mA typical |
| Built-in Energy Storage | 220 µF capacitor for input debouncing |
| Status Indicators | 32 green LEDs (one per channel) |
| Operating Temperature | 0°C to 60°C |
| Protection Features | Reverse polarity protection on inputs |
Detailed Feature Overview
This module provides 32 digital input channels in a single slot. Each channel uses an optocoupler for electrical isolation from the field. Consequently, electrical noise does not affect your control logic.
A 220 µF capacitor filters input signals for stable debouncing. You can select three input delays: 0.5 ms, 3 ms, or 6 ms. Shorter delays suit fast counting applications, while longer delays reject contact bounce.
You will find 32 green status LEDs across the front panel. These LEDs illuminate when the corresponding input detects a high signal. The 48-pin front connector accepts standard S5 wiring cables.
Installation and Compatibility
Siemens 6ES5436-6AA11 fits any S5 rack slot except the CPU position. Use the 48-pin front connector 6ES5497-4UB31 for field wiring. Connect 24 V DC sensors to the appropriate input pins carefully.
