Siemens 6ES5308-3UA11 Interface Module

High-Speed Bus Coupling for S5 Expansion Racks

The Siemens 6ES5308-3UA11 interface module connects the central controller to distributed I/O stations via a high-speed bus. This unit ensures seamless data exchange between multiple racks over extended distances. Large-scale automation systems depend on this interface for synchronized and reliable operation.

Communication Specifications and Electrical Ratings

This interface module operates on a 24 V DC supply with a permissible range of 20.4 V to 28.8 V. The unit draws a maximum current of 400 mA from the external power source. Total power dissipation measures approximately 8 watts, requiring adequate cabinet ventilation. Furthermore, the module stores up to 8 KB of configuration data for rapid system initialization.

Parameter	Specification
Model	Siemens 6ES5308-3UA11
Supply Voltage	24 V DC (20.4–28.8 V)
Current Consumption	400 mA (max)
Power Dissipation	8 W (typical)
Configuration Storage	8 KB
Transmission Rate	1.5 Mbps
Interface Type	RS-485 (galvanically isolated)
Cable Length (max)	1,200 m (at 187.5 kbps)
Stations Supported	Up to 32 per segment
Connector Type	15-pin D-sub (female)
Dimensions (W x H x D)	40 mm x 125 mm x 118 mm
Weight	0.40 kg

Galvanic Isolation and Noise Immunity

The Siemens 6ES5308-3UA11 provides 1500 V AC isolation between the backplane and the fieldbus interface. This isolation protects the central controller from ground loops and voltage surges. The module also features integrated transient suppression on all communication lines. These protective measures ensure reliable operation in electrically noisy industrial environments.

Physical Construction and Connector Details

This interface module features a compact 40 mm housing that fits standard S5 rack slots. The unit weighs approximately 0.40 kilograms, allowing straightforward installation and removal. A 15-pin D-sub female connector on the front panel provides the fieldbus interface. The module includes LED indicators for power, data exchange, and error conditions.

Network Configuration and Addressing

Users can set the station address using a rotary switch on the front panel. The module automatically detects the network baud rate during the startup sequence. A built-in termination resistor activates via a DIP switch when the unit occupies the last position. Moreover, the module supports both master-slave and peer-to-peer communication modes.

Installation and System Integration Guidelines

You can install this interface module in any slot of the S5 central or expansion rack. Connect the fieldbus cable to the 15-pin D-sub connector using shielded twisted-pair wiring. Terminate both ends of the bus segment with 120-ohm resistors for optimal performance. Always verify the station address before connecting to the network. The module operates reliably from 0°C to 60°C with proper cabinet ventilation.
