GE IS200WREAH1APR3 Turbine Control Module

This module manages Woodward relay interfaces for GE turbine control systems. You will find the GE IS200WREAH1APR3 Turbine Control Module processing speed and load signals for governing operations. Its rugged design supports continuous field duty in power generation environments.

Technical Specifications

This module contains one main processor and four relay output channels. You can also locate two analog input channels for position feedback. The GE IS200WREAH1APR3 Turbine Control Module stores no battery energy for configuration retention. Instead, it uses non-volatile flash memory for all control parameters. Therefore, this module never requires any routine battery replacement.

Control Details

The GE IS200WREAH1APR3 Turbine Control Module draws its operating power from the system backplane. You can connect Woodward actuator position sensors to the analog inputs. The module executes governor algorithms at 100 Hz update rates. Moreover, the four relay outputs drive external solenoid valves for fuel control. This design provides precise speed regulation under varying load conditions.

Mechanical Integration and Mounting

You must mount the GE IS200WREAH1APR3 Turbine Control Module carefully onto the designated mounting rails. After positioning, secure the module using four M4 screws through the corner holes. The module measures exactly 27.0 centimeters in length and 19.5 centimeters in width. Its total weight reaches approximately 0.72 kilograms for straightforward handling. Furthermore, the five status LEDs indicate processor health and output states.

Environmental and Storage Guidelines

You should store this GE IS200WREAH1APR3 Turbine Control Module in an anti-static bag away from moisture. The module operates reliably between -30°C and +65°C ambient temperature. Likewise, keep the unit away from conductive dust or strong electromagnetic fields. Because the module uses solid-state components only, it requires zero regular maintenance over its service life.
