Siemens 6AV3525-1EA41-0AX0 | SIMATIC HMI Operator Panel

Technical Overview of the Operator Panel

The Siemens 6AV3525-1EA41-0AX0 provides a compact operator interface for SIMATIC HMI applications. This panel enables machine control and process visualization through its graphical display and function keys. It connects directly to SIMATIC controllers for seamless data exchange. The design suits demanding industrial environments with robust construction.

Key Technical Specifications

This section details the core parameters for the Siemens 6AV3525-1EA41-0AX0 operator panel. Use these figures to confirm compatibility with your automation system.

Parameter	Specification
Part Number	6AV3525-1EA41-0AX0
Type	Operator Panel
Product Family	SIMATIC HMI
Display Type	TFT Color LCD
Display Size	Approx. 5.7 inches
Resolution	320 x 240 Pixels
Input Method	Membrane function keys
Communication	RS232 / RS485, MPI, PROFIBUS DP
Operating Voltage	24V DC
Dimensions (W x H x D)	Approx. 210 x 160 x 60 mm
Weight	Approx. 1.4 kg
Compatibility	SIMATIC S7 and S5 systems

Application and System Integration

This operator panel connects to the controller via MPI or PROFIBUS DP. It displays machine status, alarms, and production data with clear color graphics. The Siemens 6AV3525-1EA41-0AX0 allows operators to adjust parameters through its function keys. The integrated communication ports support multiple protocol standards.

Reliability and Performance Features

The TFT display delivers clear visibility in diverse lighting conditions. Its robust membrane keypad resists dust and moisture ingress. The panel operates reliably across a wide temperature range. Engineers choose the Siemens for its intuitive operation and durable design.
