Schneider TSXMFPP224K Flash EPROM Card

This memory extension card provides non-volatile storage for Schneider Modicon Premium PLCs. It stores user programs, data tables, and configuration parameters permanently. Therefore, it eliminates battery backup requirements for critical application code.

Physical and Memory Specifications

The Schneider TSXMFPP224K measures 8.5 cm in length and 5.5 cm in width. Moreover, its card weight equals approximately 0.03 kg for easy installation. A single 32-pin edge connector interfaces directly with the PCMCIA slot. Additionally, this memory card uses Flash EPROM technology for data retention.

Parameter	Specification
Brand	Schneider Electric
Full Model	TSXMFPP224K
Category	Modicon Flash EPROM Memory Extension
Dimensions (L x W)	8.5 cm x 5.5 cm (3.35″ x 2.17″)
Card Thickness	3.5 mm (0.14 inches)
Card Weight	0.03 kg (0.07 lbs)
Interface Type	1 x 32-pin Edge Connector (PCMCIA Type I)
Memory Type	Flash EPROM (NOR)
Memory Capacity	224 kB (Program + Data Storage)
Program Storage	128 kB (User Application Code)
Data Storage	96 kB (Constants and Configuration)
Read Access Time	150 ns (Typical)
Write Endurance	100,000 Cycles (Minimum)
Data Retention	10 Years (Minimum at 55°C)
Battery Requirement	None (Non-Volatile)
Compatible Processors	TSX Premium P57 Series CPUs
Programming Software	PL7 Pro or Unity Pro
File Transfer	PC to Card via PCMCIA Adapter
On-Board Components	2 Flash Memory Chips + 1 Controller IC + 1 Write Protect Switch + 4 Capacitors
Energy Storage	2 x 1 µF Ceramic Capacitors (Decoupling Only)
Operating Voltage	3.3 VDC or 5 VDC (from PCMCIA Slot)
Power Consumption	0.1 W (Typical)
Operating Temperature	0°C to +55°C (32°F to 131°F)
Storage Temperature	-40°C to +85°C (-40°F to 185°F)
Write Protection	Mechanical Slide Switch (On Card Body)

Memory Architecture and Non-Volatile Storage

The Schneider TSXMFPP224K uses Flash EPROM technology for permanent data retention. Specifically, NOR Flash architecture allows byte-level read access for fast program execution. In addition, this memory card requires no battery backup for data preservation. Moreover, the card retains stored programs for up to 10 years without power. Consequently, you can store critical application code safely without periodic battery changes.

Program and Data Storage Features

This memory extension card provides 224 kilobytes of total storage capacity. For instance, 128 kilobytes hold the user’s ladder logic and function blocks. In addition, 96 kilobytes store configuration constants, recipe data, and parameters. Furthermore, the 150 ns access time ensures fast program loading to the CPU. Thus, this card serves as reliable backup for production-critical PLC applications.

Write Protection and Installation

A mechanical slide switch on the card body enables write protection. Specifically, moving the switch to the lock position prevents accidental overwrites. In addition, the card fits into any standard PCMCIA Type I slot. Moreover, you do not need to open the PLC cabinet for installation. Therefore, the Schneider TSXMFPP224K suits field technicians and maintenance engineers perfectly.

Compatibility and Usage Guidelines

This memory card works with TSX Premium P57 series processors exclusively. For example, compatible models include P571, P572, P573, and P574 CPUs. In addition, you can transfer programs from a PC using a PCMCIA adapter. However, do not remove the card while the PLC writes data to it. Thus, always power down or disable writes before card extraction.
