Honeywell MC-TAIL02 51304437-150 Analog Input

Product Overview

This analog input termination board provides a centralized wiring interface for field transmitters. It connects multiple analog sensors directly to Honeywell TDC 3000 input modules. The MC-TAIL02 51304437-150 organizes field cabling and simplifies maintenance tasks significantly. Its compact design reduces installation time and eliminates wiring errors in control cabinets. This board ensures reliable signal transmission from field devices to the control system.

Technical Specifications

The MC-TAIL02 51304437-150 measures 27.9 cm in height, 17.8 cm in depth, and 2.5 cm in width. It weighs approximately 0.75 kg, including all terminal blocks and mounting hardware. This board operates from the 24 VDC supply with a current draw of 100 mA typical. It provides sixteen discrete termination points for analog input signals from field transmitters. Each terminal accommodates wire sizes from 0.5 mm² to 2.5 mm² (20 to 14 AWG). The board includes built-in surge suppression for each channel to protect against transients. It also provides individual fusing for each input circuit to prevent overcurrent damage. The termination board connects to the main input module through a 50-pin ribbon cable. It features clearly numbered terminal positions for simplified wiring identification. The front panel includes LED indicators for power and channel activity monitoring.

Signal Routing and Protection Features

This board routes field signals to the appropriate input module with minimal signal degradation. It filters common-mode noise to ensure accurate measurement and reliable operation. The MC-TAIL02 51304437-150 includes reverse-polarity protection on each input channel. Users can disconnect individual channels without interrupting other inputs. The board also provides test points for troubleshooting each signal path.

Physical and Electrical Parameters

Parameter	Specification
Dimensions (H x D x W)	27.9 cm x 17.8 cm x 2.5 cm
Weight	0.75 kg
Power Supply	24 VDC
Current Draw	100 mA typical
Termination Points	16 analog inputs
Wire Gauge	0.5 to 2.5 mm² (20-14 AWG)
Connector Type	50-pin ribbon cable header
Surge Suppression	Built-in per channel
Circuit Protection	Individual fusing
Signal Filtering	Common-mode noise rejection
Reverse Polarity	Protected inputs
Test Points	Available per channel
LED Indicators	Power, channel activity
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C

Installation and Wiring Guidelines

Mount the MC-TAIL02 51304437-150 securely inside the control cabinet using the provided hardware. Connect the 50-pin ribbon cable to the corresponding input module interface. Terminate each field transmitter wire to its designated terminal position with proper torque. Verify all connections before applying power to avoid potential damage. The board provides clear labeling for each terminal to simplify installation and maintenance. Regular inspection ensures reliable long-term performance.

Typical Applications

This termination board serves refineries, chemical processing plants, and power generation facilities. It connects pressure, temperature, and flow transmitters to the control system. The MC-TAIL02 51304437-150 also supports level sensors and analytical instruments. Its sixteen-point density suits applications requiring multiple analog inputs.
