Core Functionality and System Role
The Honeywell analog input module captures precise field signals for the Experion PKS and C300 control systems. This high-performance module supports multiple signal types, including 4-20 mA, thermocouples, and RTDs. Its robust design ensures accurate process variable acquisition in demanding industrial environments. Furthermore, the module handles HART digital communication for intelligent device integration.
Technical Specifications
The following table details the core technical parameters for the Honeywell CC-PAIM01 51405045-175:
| Parameter | Specification |
|---|---|
| Model Number | CC-PAIM01 51405045-175 |
| Product Type | Analog Input Module / Low-Level Analog Mux |
| System Compatibility | Experion PKS, C300 Controller |
| Input Channels | 8 channels (differential, isolated) |
| Supported Signal Types | 4-20 mA, TC, RTD, mV, Voltage (±100mV, ±1V, ±10V) |
| Resolution | 16-bit A/D conversion |
| Accuracy | ±0.05% of span (typical) |
| CMRR | >100 dB (50/60 Hz) |
| Update Rate | 100 ms per channel (typical) |
| Isolation | Channel-to-channel, channel-to-bus |
| Dimensions (W × H × D) | 5.5 × 14.5 × 15.5 cm (approx.) |
| Weight | 0.28 – 0.3 kg |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Hot-Swap Support | Yes |
| Certifications | CE, UL, cUL, ATEX, IECEx |
Design and Integration Features
The Honeywell CC-PAIM01 51405045-175 features a compact, modular design for straightforward installation in C300 I/O racks. The module supports hot-swap capability, which allows replacement without system shutdown. Its patented heat channeling form factor ensures reliable thermal management. The module integrates seamlessly with Honeywell I/O Termination Assemblies (IOTAs) for simplified field wiring. On-board diagnostics and LED indicators provide real-time status monitoring.
System Compatibility and Use Cases
The Honeywell CC-PAIM01 51405045-175 works with Experion PKS and ControlEdge platforms. It suits critical applications in oil and gas, chemical processing, and power generation. The module supports both standard and redundant configurations for high availability systems. Users should verify signal type and channel configuration for specific application requirements.
