GE QPK-3D200-C2P – Operator Interface for Machine Control

The GE QPK-3D200-C2P provides a graphical touch interface for industrial machinery. This operator interface measures 220 mm in width and 150 mm in height. It has a depth of 45 mm, so it fits standard panel cutouts easily. The unit weighs 1.1 kg, making panel mounting secure and stable.

Display Specifications and Touch Technology

This operator interface features a 5.7-inch color TFT display with QVGA resolution. The GE QPK-3D200-C2P delivers 320 by 240 pixels for clear machine graphics. It uses resistive touch technology for reliable operation with gloved hands. The display achieves a brightness of 400 cd/m² for good visibility. A viewing angle of 70 degrees in all directions ensures readability.

Communication Ports and Connectivity

You will find one RS-232 port and one RS-485 port on this operator interface. The GE QPK-3D200-C2P also includes a USB 1.1 port for program uploads. An Ethernet port supports 10/100 Mbps for network connectivity. The unit communicates with most major PLC brands using built-in drivers. A CF card slot provides additional storage for recipes and logs.

Internal Architecture and Memory Configuration

The operator interface contains two circuit boards inside its plastic housing. The GE QPK-3D200-C2P includes 16 MB of SDRAM for screen execution. It also provides 8 MB of flash memory for persistent data storage. A dedicated 32-bit RISC processor handles graphics and communication tasks. The module stores 100 µF of capacitance for power supply filtering.

Power Requirements and Environmental Tolerance

The GE QPK-3D200-C2P draws 400 mA at 24V DC during normal operation. It tolerates a voltage range from 20.4V DC to 28.8V DC. The unit operates reliably from 0°C to 50°C ambient temperature. It tolerates humidity levels up to 90 percent without any condensation issues. The front panel carries an IP65 rating for washdown resistance.

Below is a complete summary of its technical specifications.

The GE QPK-3D200-C2P replaces older operator panels in GE control systems. You do not need any special configuration software beyond standard tools. This unit also supports remote monitoring via built-in web server functions. Consequently, it suits packaging machines, conveyors, and small process lines.
