GE IC690ACC900A Cable Adapter | VersaMax Programming

This cable adapter connects a PC serial port to GE VersaMax CPU modules. It converts standard RS-232 signals to the module’s serial communication protocol. You will need this accessory for uploading ladder logic or monitoring system status.

Key Technical Specifications

Parameter	Details
Model Number	IC690ACC900A
Brand	GE (General Electric)
Category	Cable Adapter / Programming Accessory
Dimensions (L x W x H)	200 mm x 45 mm x 20 mm
Weight	120 grams
Component Count	24 discrete components (resistors, capacitors, IC)
Onboard Energy Storage	220 µF single capacitor
Connector Type A	9-pin D-sub female (PC side)
Connector Type B	15-pin D-sub male (CPU side)
Cable Length	200 mm (fixed pigtail)
Supported Protocol	RS-232 at 9600 to 115200 baud
Voltage Isolation	None (direct wired)

Physical Dimensions and Cable Construction

This adapter measures 200 mm in length and 45 mm in width. Its height reaches 20 mm at the connector housing. The unit weighs 120 grams, adding minimal bulk to your programming kit. A fixed pigtail cable connects the two D-sub connectors permanently.

Internal Circuitry and Energy Storage

Twenty-four discrete components populate the small internal PCB. A 220 µF capacitor filters noise from the PC serial port. This capacitor also maintains signal levels during brief voltage drops. Consequently, the adapter provides reliable communication even with older laptop ports. A line driver IC converts voltage levels between RS-232 and the CPU’s logic interface.

Connector Configuration and Compatibility

A 9-pin female D-sub plugs directly into your computer’s serial port. A 15-pin male D-sub connects to the VersaMax CPU programming port. You do not need any additional adapters or gender changers for this link. The adapter works with IC200CPU001, IC200CPU002, and later VersaMax models. Therefore, this single cable supports your entire VersaMax fleet.

Programming Use and Baud Rate Support

You can upload ladder logic, download configuration changes, and monitor live data. The adapter supports baud rates from 9600 to 115200 automatically. Simply select the matching speed in your Proficy Machine Edition software. LED indicators are not present on this passive adapter design. Always disconnect the cable before powering down the PLC system.
