GE IC610PRG105B Hand Held Programmer

Technical Specifications and Physical Characteristics

This hand held programmer supports the GE Series Six PLC family. The GE IC610PRG105B allows direct on-site program editing without a computer. You can enter, modify, or monitor ladder logic easily. Its rugged enclosure withstands harsh industrial environments. The device weighs approximately 1.2 kilograms. Its dimensions measure 28 cm in length, 12 cm in width, and 5 cm in height.

Parameter	Specification
Brand	GE Automation
Model	IC610PRG105B
Category	Hand Held Programmer / Portable Programming Unit
Weight	1.2 kg
Dimensions (L x W x H)	28 cm x 12 cm x 5 cm
Display Type	LCD alphanumeric (2 lines x 16 characters)
Keypad	42-key membrane keypad
Interface Type	RS-422 serial (dedicated cable)
Number of Components	Single integrated unit with cable
Energy Storage	None (no internal battery)
Power Source	Draws power from Series PLC backplane

Connectivity and Programming Features

You connect this programmer directly to the Series Six CPU via its RS-422 port. The included cable provides both data and power transmission. Therefore, the unit requires no external power supply or batteries. You can perform online edits while the PLC continues running. The LCD screen displays two lines of sixteen characters each. This display shows rung numbers, contact types, and timer values. The 42-key membrane keypad includes dedicated function keys. For instance, you will find specific keys for contacts, coils, timers, and counters.

Operational Guidelines

You must attach the cable firmly before powering up the PLC system. The programmer draws operational current directly from the backplane connection. It stores no programs internally when disconnected. Consequently, you should save all changes to the PLC memory immediately. The unit supports all standard Series Six instruction sets. You can navigate through program steps using the arrow keys. This hand held programmer remains a practical backup tool for legacy systems.
