GE DS200SIOCG1A DS200SIOCG1ADA VME I/O Board

This GE DS200SIOCG1A DS200SIOCG1ADA VME Stand I/O Board provides discrete input and output expansion for Mark V systems. The board connects directly to the VME backplane for high-speed data exchange. You will find this component in many GE turbine control applications. The DS200SIOCG1ADA variant includes a conformal coating for harsh industrial environments.

Technical Specifications

Parameter	Specification
Full Model	GE DS200SIOCG1A DS200SIOCG1ADA VME Stand I/O Board
Category	VME Stand I/O Board
Digital Inputs	32 Opto-Isolated Channels (24V DC)
Digital Outputs	16 Open-Collector Channels (24V DC, 0.5A)
VME Interface	A24/D16 Slave
Update Rate	1 kHz for All Channels
Input Filter	Programmable from 0 to 10 ms
Dimensions (H x W)	160 mm x 100 mm (6U Format)
Weight	Approximately 0.45 kg
Connectors	2 x 50-Pin Ribbon Headers, 1 x P1/P2 Backplane
Component Count	178 Discrete Components
Energy Storage	8 x 10 µF Decoupling Capacitors

I/O Processing and Isolation Features

The GE DS200SIOCG1A DS200SIOCG1ADA VME Stand I/O Board optically isolates all field inputs from the logic side. Each input channel includes a programmable debounce filter for noise rejection. The output channels feature short circuit protection with automatic shutdown. Furthermore, the board maps all I/O directly into VME memory space. Consequently, the main processor can access status without complex communication protocols.

Installation and Connection Steps

Mount this GE DS200SIOCG1A DS200SIOCG1ADA VME Stand I/O Board into any standard 6U VME rack slot. First, connect field wiring to the two 50-pin ribbon headers. After that, seat the board firmly into the P1 and P2 backplane connectors. Then, secure the board using the front panel ejector handles. Finally, configure the base address using the onboard DIP switches before powering up.

Energy Discharge and Safety Notice

This GE DS200SIOCG1A DS200SIOCG1ADA VME Stand I/O Board stores minimal energy in its capacitors. However, you must wait 30 seconds after power removal before handling. The eight decoupling capacitors discharge through internal resistors. Never connect voltages above 30V DC to any input or output channel.

Status Indication and Diagnostics

A green LED indicates the board has VME power and bus access. A yellow LED flashes during active input scanning cycles. A red LED illuminates when any output channel detects an overload condition. These indicators help technicians verify board operation without software tools.
