GE A66L-2001-0998#50B Ribbon Cable

Reliable Signal Interconnect for CNC Systems

The GE A66L-2001-0998#50B transmits signals between CNC modules and display units. This ribbon cable measures exactly 500 mm in total length. It contains 50 individual conductors in a flat parallel arrangement. Consequently, users achieve clean wire routing inside control cabinets.

Physical Specifications and Construction

This cable assembly weighs approximately 0.11 kg. The GE A66L-2001-0998#50B features two 50-pin IDC connectors. One connector attaches to each end of the ribbon. The cable uses 28 AWG stranded tinned copper wires. Each conductor has a PVC insulation layer for durability.

The assembly stores no electrical energy whatsoever. It acts purely as a passive interconnection medium. Furthermore, the GE A66L-2001-0998#50B includes a red stripe on wire number one. This stripe assists technicians with proper orientation during installation.

Parameter	Specification
Brand	GE
Model	A66L-2001-0998#50B
Category	Ribbon Cable Connector
Length	500 mm
Conductor Count	50
Connector Type	50-pin IDC (both ends)
Wire Gauge	28 AWG
Conductor Material	Stranded tinned copper
Insulation	PVC
Weight	0.11 kg
Energy Storage	None
Polarity Marking	Red stripe on pin 1

Connector and Contact Details

Each IDC connector housing uses a gray thermoplastic material. The GE A66L-2001-0998#50B has gold-plated contacts for reliable signal transfer. These contacts resist corrosion in humid environments. The insulation displacement design pierces wire insulation upon crimping. Therefore, you do not need to strip individual conductors beforehand.

Compatibility and Usage Guidelines

This cable connects the graphic board to the operator panel display. It also links the main CPU to keyboard interface boards. The GE works exclusively with 50-pin header connectors. Do not force this cable onto 40-pin or 64-pin headers. The cable bends to a minimum radius of 25 mm. Repeated tight bending may damage internal conductors over time.

Installation Recommendations

Always align the red stripe with pin one on both boards. The GE A66L-2001-0998#50B locks securely through friction fit only. Use cable ties to secure loose sections inside the cabinet. Keep the cable away from high-voltage AC wires. This practice prevents electrical noise coupling into sensitive signals.
