Fuji GU-10 Touch Screen Module | MICREX-SX 10.4" HMI

Intuitive Operator Interface for Machine Control

This touch screen module provides a graphical interface for your MICREX-SX automation system. The Fuji GU-10 connects directly to the CPU via the backplane bus. It displays real-time process values and alarm messages on a color LCD screen. Operators interact with the system using finger touches instead of physical buttons. Consequently, this HMI module reduces panel space and simplifies machine operation.

Display Specifications & Touch Technology

The Fuji GU-10 features a high-resolution color display for clear visibility. You can create custom screens with buttons, gauges, and trend graphs. The resistive touch technology works with gloved hands for industrial safety. A built‑in flash memory stores multiple screen pages locally. Therefore, the module operates independently without continuous CPU communication.

Parameter	Detailed Specification
Operating Temperature	0°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity Range	20% to 85% RH (no condensation)
Display Size	10.4 inches diagonal
Display Type	TFT color LCD
Resolution	640 x 480 pixels (VGA)
Touch Technology	Resistive (gloved hand operable)
Backlight Type	CCFL (replaceable)
Backlight Life	50,000 hours typical
Screen Memory	4 MB flash (non‑volatile)
Max Screen Pages	500 (user‑configurable)
Communication Interface	MICREX-SX backplane bus
Status LEDs	2 (POWER, COM)
Power Supply	24V DC via backplane
Current Draw	350 mA typical
Energy Storage	None (flash memory retains data)

Installation & System Integration

You insert the Fuji GU-10 into any available slot of your MICREX-SX rack. The module automatically mounts flush with the cabinet door for operator access. You design screen layouts using the standard Fuji HMI configuration software. The module then stores your project in its internal flash memory permanently. Consequently, the HMI boots instantly without loading data from the CPU.

Operational Advantages & User Experience

The Fuji GU-10 replaces dozens of physical pushbuttons and indicator lights. You can create multi‑language screens for global equipment deployment. The resistive touch screen responds reliably even with heavy work gloves. A bright color display remains visible in various lighting conditions. Therefore, this Fuji touch module improves operator efficiency and reduces panel wiring costs.
