The Bently Nevada 21000-16-10-00-124-03-02 houses proximity probes and shields them from mechanical damage. Engineers choose this assembly when harsh plant conditions threaten exposed sensor installations. Consequently, the housing delivers stable probe mounting across the full machine operating range.
Physical Dimensions and Weight Data
Bearing housings often restrict how technicians arrange probe mounting hardware. Therefore, the Bently Nevada 21000-16-10-00-124-03-02 keeps a compact profile that fits tight clearances. It weighs roughly 0.45 kg and measures 16 mm in mounting thread size. Additionally, its overall length reaches 124 mm including the threaded body.
Interfaces and Connectivity Features
Reliable signal transmission depends on secure coaxial connections at every probe exit point. The Bently Nevada 21000-16-10-00-124-03-02 provides a standard coaxial connector for extension cable mating. Furthermore, the stainless steel body resists corrosion in humid plant environments. The assembly accepts standard 3300 XL probes without additional adapters.
Component Count and Construction Details
Internal construction shapes both measurement stability and service life. The Bently Nevada 21000-16-10-00-124-03-02 integrates a housing body, seal assembly, and locking nut. Moreover, the housing withstands temperatures up to 177°C continuously. The sealed design protects probes from oil, dust, and moisture ingress.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Assembly Type | Proximity probe housing |
| Mounting Thread | 16 mm |
| Overall Length | 124 mm |
| Weight | 0.45 kg |
| Body Material | Stainless steel |
| Connector Type | Coaxial |
| Seal Type | O-ring, oil-resistant |
| Operating Temperature | -35°C to 177°C |
| Pressure Rating | 10 bar |
| Compatible Probes | 3300 XL series |
| Cable Exit | Rear, coaxial |
| Isolation | Galvanic |
| Locking Nut | Included |
Mounting Performance and Compliance
Stable probe mounting directly influences overall vibration monitoring accuracy. The Bently Nevada holds probe position within ±0.05 mm under vibration. Meanwhile, the sealed housing resists oil, dust, and moisture interference. These features support dependable operation in harsh turbine environments.
Industrial sites also demand strict safety certifications before deployment. The assembly complies with API 670 requirements for machinery protection systems. In addition, it meets CE and UL standards for electromagnetic compatibility. These credentials ensure safe integration with 3300 XL monitoring hardware.
