Bently Nevada 177989-01 Prox Accel Velom Module

The 177989-01 Prox Accel Velom module from Bently Nevada captures proximity, acceleration, and velocity signals inside machinery protection systems. Plant engineers install this module whenever one card must handle several transducer types at once. Consequently, it delivers conditioned data for vibration, position, and speed evaluation without extra rack hardware.

Key Technical Specifications

The table below outlines the main physical and electrical parameters of the 177989-01 module.

Parameter	Specification
Product Type	Prox Accel Velom Module
Compatibility	Bently Nevada machinery protection systems
Dimensions	Approximately 254 mm x 127 mm x 51 mm
Weight	Approximately 1.0 kg (2.2 lbs)
Mounting	Rack frame or panel mounting base
Interface	Backplane bus and multi-type transducer input terminals
Connectors	Multi-pin connector and coaxial input ports
Component Count	Multiple signal conditioners, integrators, filters, and driver circuits
Energy Storage	On-board capacitors for signal and voltage stabilization
Input Channels	Multiple transducer input channels
Signal Types	Proximity, acceleration, and velocity input support
Operating Temperature	0 degrees C to 60 degrees C
Storage Temperature	-40 degrees C to 85 degrees C
Humidity	5% to 95% non-condensing

Functional Overview

This module accepts proximity, accelerometer, and velocity signals and conditions each for monitor processing. Therefore, it lets one card serve several measurement types across a machine train. The 177989-01 also integrates acceleration signals to produce velocity readings where needed. Meanwhile, its onboard energy storage stabilizes signals during transient voltage fluctuations.

Installation and Handling Notes

Always verify transducer gap voltages before connecting sensors to the 177989-01. In addition, check that input type settings match each installed sensor. Tighten all connectors fully to prevent intermittent data loss. Finally, confirm channel readings during commissioning.
