Bently Nevada 175794-01 3701/60 Simplex Terminal Base

The 175794-01 3701/60 simplex terminal base from Bently Nevada provides a wiring interface for 3701 series monitors inside machinery protection racks. Technicians install this base whenever field cables must land reliably on a single-channel monitor position. Consequently, it simplifies wiring and keeps transducer connections stable under vibration.

Key Technical Specifications

The table below outlines the main physical and electrical parameters of the 175794-01 3701/60 base.

Parameter	Specification
Product Type	Simplex Terminal Base
Compatibility	Bently Nevada 3701 series monitor systems
Dimensions	Approximately 150 mm x 100 mm x 40 mm
Weight	Approximately 0.45 kg (1.0 lbs)
Mounting	Rack frame or panel mounting base
Interface	Screw terminal field connections
Connectors	Multiple screw terminal positions
Component Count	Terminal blocks, retaining hardware, and labeling plates
Energy Storage	Filter capacitors for signal smoothing
Terminal Count	Multiple field wiring positions
Channel Configuration	Single-channel simplex wiring support
Operating Temperature	0 degrees C to 60 degrees C
Storage Temperature	-40 degrees C to 85 degrees C
Humidity	5% to 95% non-condensing

Functional Overview

This base accepts field wires and routes each signal to the correct monitor channel. Therefore, it keeps cable management clean during installation and retrofit work. The 175794-01 3701/60 also provides a stable mechanical anchor that resists vibration loosening. Meanwhile, its onboard energy storage smooths low-level signals against electrical noise.

Installation and Handling Notes

Always strip field wires to the recommended length before inserting them. In addition, tighten each screw terminal to the specified torque value. Verify channel mapping against your loop drawings before powering the rack. Finally, label every terminal clearly for future maintenance work.
