ABB Bailey IEPDP01 Power Distribution Panel

Panel Overview

This power distribution panel routes AC and DC power to multiple INFI 90 racks. You can install ABB Bailey IEPDP01 inside main control room cabinets. The unit accepts incoming power from plant supply breakers. It distributes fused outputs to individual rack power supplies.

Technical Specifications

Parameter	Value
Dimensions (W x H x D)	400 mm x 300 mm x 120 mm
Weight	3.8 kg
Input voltage	120V AC or 230V AC (selectable)
Input current rating	15A maximum
Output circuits	8 fused outputs
Output voltage	Same as input (pass-through)
Fuse type per output	5A, 10A, or 15A (field-selectable)
Fuse indication	LED per output (blown fuse)
Surge protection	Metal oxide varistor (MOV) on input
Circuit breaker	Main input (15A thermal-magnetic)
Wiring termination	Screw terminals (up to 10 AWG)
Enclosure rating	IP20 (finger-safe)
Total components	48 discrete parts
Energy storage type	None (passive distribution only)
Operating temperature	-10°C to +50°C

Panel Construction and Components

The panel houses a PCB with copper bus bars for power distribution. Eight fuse holders line the front face for easy access. Moreover, 48 discrete components include fuses, LED indicators, and a main breaker. The MOV surge suppressor clamps input voltage spikes below safe levels. Consequently, downstream power supplies receive clean, protected input power.

Installation Process

You can mount ABB Bailey IEPDP01 inside standard 19-inch control cabinets. The main input terminals accept plant AC supply wiring directly. Furthermore, each output connects to an INFI 90 rack power supply via field wiring. LED indicators show blown fuses for each output circuit clearly.

Performance Advantages

This panel distributes power to up to eight INFI 90 racks from a single source. The main circuit breaker provides overcurrent protection for entire panel. Therefore, a short in one rack does not affect other racks. The MOV surge protection also shields all connected supplies from lightning strikes.

Safety and Compliance

ABB Bailey IEPDP01 meets CE, UL 508A, and RoHS standards. The panel stores no electrical energy after AC removal. Hence, technicians face no capacitor discharge hazards during fuse replacement or maintenance.
