Woodward 5464-013 Semi-Insulated Input Driver

Product Overview

The Woodward 5464-013 is a semi-insulated input driver, specifically designed for use with Woodward’s NETCON 5000 system. This device ensures robust performance in machine control and PLC applications. While the Woodward 5464-013 has been discontinued by the manufacturer, it remains a highly reliable choice for legacy systems.

Key Features

Reliable Input Driver: The Woodward allows precise control over field devices, making it an ideal choice for a variety of industrial applications.
LED Fault Indicator: A red LED light indicates faults, allowing for quick diagnosis and minimizing downtime.
Panel Mount: The design allows easy and secure mounting in a standard control panel, saving valuable space.

Technical Specifications

Specification	Details
Part Number	5464-013
Category	PLCs/Machine Control
Subcategory	PC Board PLC/Add-On Board
Model	NETCON 5000
Mounting Type	Panel Mount
Fault Indicator	Red LED for Fault
Weight	1.85 lbs (0.84 kg)
Status	Discontinued by Manufacturer

Environmental Specifications

Specification	Details
Operating Temperature	-40°C to +85°C
Humidity Range	5% to 95% Non-condensing

Applications

The Woodward 5464-013 finds its place in numerous industrial environments, including:

PLC Systems: Controls inputs for various machine automation systems.
Control Panels: Easily integrates into custom-built or pre-existing panels.
Legacy Systems: Trusted for use in older Woodward NETCON setups, ensuring reliable operation in long-term applications.

Installation and Use

Effortless Installation: The panel mount design allows for secure installation into most standard control panels.
Durability: Despite being discontinued, the Woodward continues to provide outstanding performance in industrial settings.
Quick Maintenance: The LED indicator helps operators detect faults quickly, significantly reducing system downtime and improving maintenance efficiency.
