Siemens 6EV1352-5BK00 Power Supply

This power supply unit converts AC mains into stable 24V DC output. The Siemens 6EV1352-5BK00 belongs to the SITOP power supply family. You can mount this unit on standard DIN rails inside control cabinets. Its rugged design supports continuous operation in demanding industrial environments.

Physical Dimensions and Mounting Configuration

The Siemens 6EV1352-5BK00 measures 7.2 cm in overall width. Its total depth reaches 12.5 cm including terminal covers. This power supply weighs approximately 0.85 kg. A metal enclosure provides excellent heat dissipation and shielding. Four clips secure the unit to a 35 mm DIN rail. A green LED indicates proper output voltage presence.

Input and Output Specifications

This unit accepts 85 to 264V AC input voltage automatically. The Siemens 6EV1352-5BK00 also operates on 110 to 300V DC input. The module delivers 24V DC at 5.0A continuously. Output power reaches 120W under normal operating conditions. Built‑in overload protection shuts down the unit during short circuits. Furthermore, the module resumes operation automatically after fault removal.

Parameter	Specification
Product Type	Switch mode power supply
Product Family	Siemens SITOP
Input Voltage (AC)	85 to 264V AC ±10%
Input Voltage (DC)	110 to 300V DC
Input Frequency	47 to 63 Hz
Inrush Current	25A max at 230V AC
Output Voltage	24V DC ±1%
Output Current	5.0A continuous
Output Power	120W
Ripple and Noise	< 50 mV peak‑to‑peak
Efficiency	90% typical at full load
Hold‑Up Time	20 ms at 230V AC
Dimensions (W x H x D)	72 mm x 125 mm x 125 mm
Weight	0.85 kg (1.87 lbs)
Terminal Type	Screw terminals (input: 3 pins, output: 4 pins)
Wire Size	0.5 to 2.5 mm²
Number of Components	1 main board, 1 heatsink, 1 fan
Internal Energy Storage	560 µF capacitor bank
Protection Features	Overload, short circuit, overvoltage
LED Indicators	DC OK (green)
Cooling Method	Natural convection
Operating Temperature	-10°C to +60°C
Protection Class	IP20

Energy Storage and Hold‑Up Performance

A 560 µF capacitor bank stores energy for brief power interruptions. The Siemens 6EV1352-5BK00 provides 20 ms of hold‑up time at full load. This storage allows the CPU to complete critical operations safely. Consequently, system shutdowns occur gracefully rather than abruptly.

Protection Circuits and Diagnostic Features

Overload protection activates when output current exceeds 6.0A. Short circuit protection responds within 30 µs of fault detection. The green DC OK LED confirms proper output voltage presence. Therefore, maintenance personnel can verify power status at a glance. Overvoltage protection clamps the output at 28V maximum.

Installation and Wiring Guidelines

Clip the unit onto a 35 mm DIN rail until it clicks. The Siemens 6EV1352-5BK00 accepts solid or stranded wires from 0.5 to 2.5 mm². Connect the AC input wires to the three‑pin terminal block. Route DC output wires separately from AC input cables. This separation reduces electrical noise on the 24V DC bus.
