Siemens 6ES7675-1DK40-2AM0 SIMATIC IPC427C Bundle

Compact Industrial PC Package for Control Room Applications

This bundle delivers a complete industrial computing solution for automation and visualization tasks. It combines a high-performance IPC with pre-installed software in one convenient package. Many facilities deploy this system for SCADA, HMI, and data logging applications. The unit offers reliable performance in harsh industrial environments.

Technical Specifications

Parameter	Specification
Model	6ES7675-1DK40-2AM0
Dimensions	262 mm × 134 mm × 73 mm (W × H × D)
Weight	2.10 kg
Power Supply	24 V DC ±20%
Power Consumption	30 W typical
Processor	Intel Atom D525 (dual-core, 1.8 GHz)
RAM	2 GB DDR3 (soldered)
Storage	64 GB SSD (SATA)
Operating System	Windows Embedded Standard 7 (pre-installed)
Communication Interfaces	2 × Gigabit Ethernet, 4 × USB 2.0, 1 × DVI-I
Serial Ports	2 × RS-232/422/485 (configurable)
Expansion Slots	1 × PCI, 1 × CompactFlash
Display Support	Dual-monitor capable (DVI-I)
Operating Temperature	0°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity Range	5% to 80% RH (non-condensing)
Protection Class	IP20
MTBF	50,000 hours
Certifications	CE, UL, cULus, ATEX, FM

Processing Engine and Memory Configuration

This bundle includes an Intel Atom D525 processor running at 1.8 GHz. The dual-core architecture supports multitasking for control and visualization. Soldered 2 GB of DDR3 RAM ensures reliable operation without connection issues. A 64 GB solid-state drive provides fast boot times and data access.

Pre-Installed Software and Bundle Value

The unit ships with Windows Embedded Standard 7 pre-installed and configured. This operating system provides a stable platform for automation applications. Users can install SIMATIC WinCC or other HMI software directly. The bundle saves engineering time on setup and configuration tasks.

Communication Ports and Connectivity

Two Gigabit Ethernet ports support redundant network connections for high availability. Four USB 2.0 ports connect to peripheral devices such as keyboards and mice. Configurable serial ports support RS-232, RS-422, and RS-485 field devices. A DVI-I port drives dual displays for operator workstations.

Expansion Capabilities and Storage Flexibility

The system includes one PCI expansion slot for add-in interface cards. A CompactFlash slot provides additional storage expansion possibilities. These options allow customization for specific application requirements. Users can adapt the system to evolving plant needs over time.

Power Supply and Energy Consumption

This IPC draws 30 W typical from a 24 V DC supply. The wide ±20% tolerance compensates for voltage fluctuations in industrial settings. The unit contains no internal batteries for main power backup. An external UPS system provides protection against power interruptions.

Mechanical Construction and Physical Attributes

The system measures 262 mm wide with a total weight of 2.10 kg. The fanless design eliminates moving parts for enhanced reliability. IP20 protection suits use inside control cabinets and equipment racks. The compact form factor saves valuable installation space.

Environmental Tolerances and Reliability

This industrial PC operates from 0°C to 50°C for stable performance. The solid-state storage withstands vibration and shock better than mechanical drives. An MTBF of 50,000 hours ensures long-term availability. These specifications suit demanding continuous-operation applications.

Safety Certifications

The 6ES7675-1DK40-2AM0 holds CE, UL, cULus, ATEX, and FM certifications. These approvals permit deployment in industrial and hazardous locations. Each unit undergoes burn-in testing before shipment. This quality assurance guarantees reliable field performance.
