Siemens 6ES7194-2LN10-1AC0 M8 Cable

Reliable Power Connection for Distributed I/O Systems

The Siemens 6ES7194-2LN10-1AC0 provides a robust power cable for the SIMATIC ET 200AL distributed I/O system. This cable delivers 24 VDC power to the ET 200AL modules through a secure M8 connection. Its 10-meter length offers flexibility for mounting distributed I/O stations across machinery or production lines. The single-sided pre-assembly with an M8 socket simplifies installation and reduces wiring time significantly .

Key Technical Specifications

Parameter	Specification
Product Model	Siemens 6ES7194-2LN10-1AC0
Brand	Siemens
Category	Power Cable / Sensor-Actuator Cable
Product Family	SIMATIC ET 200AL
Connector Type (1)	M8 socket, straight (4-pole)
Connector Type (2)	Open end (bare wires)
Cable Length	10 meters
Number of Cores	4
Cable Designation	4 Li9Y 0.50 mm² Y
Outer Diameter	5.2 mm
Sheath Material	PVC (gray)
Core Insulation	PP (polypropylene)
Color Coding	White / Brown / Blue / Black
Degree of Protection	IP65 / IP67 (when mated)
Bending Cycles	2,500,000 (cable carrier compatible)
Min. Bending Radius	26 mm (single) / 52 mm (multiple)
Ambient Temperature	-30°C to +80°C
Weight per Meter	44 g/m
Net Weight	0.444 kg
Country of Origin	Germany
RoHS Compliant	Yes

Cable Design and Durability Features

The Siemens 6ES7194-2LN10-1AC0 features a durable PVC sheath that withstands industrial environments. The cable supports 2.5 million bending cycles, making it suitable for use in cable carriers. The 4-core design with color-coded conductors simplifies wiring and reduces connection errors. The gray sheath offers excellent visibility for identification and maintenance. The M8 connector provides IP65/IP67 protection when properly mated .

System Integration and Application

This power cable is specifically designed for connecting SIMATIC ET 200AL modules to a 24 VDC power supply . The open end allows users to connect directly to terminal blocks or power distribution units. The 10-meter length provides sufficient reach for flexible system layouts across machinery. The cable supports the robust ET 200AL system, which is splash-proof, oil-tight, and dust-tight for demanding environments .
