Siemens 6ES5390-0UA11 Simatic S5 Text Display

The 6ES5390-0UA11 serves as a text display for SIMATIC S5 automation systems. This unit shows process values and diagnostic messages for operator monitoring. Its rectangular frame measures 232 millimeters in width. The display height reaches 140 millimeters exactly. Depth stays at 85 millimeters. You will find this unit weighs approximately 0.65 kilograms. Therefore, installation requires mounting the unit into a control panel cutout. One 25-pin D-sub connector provides the interface to the PLC.

Physical Layout and Connectors

The front panel features a 2-line alphanumeric LCD display. You will find six membrane keys for operator input below the screen. One 25-pin D-sub port connects to the S5 CPU. Four status LEDs indicate power, communication, and alarm conditions. Four mounting screws secure the unit to the panel cutout.

Technical Specifications

Parameter	Specification
Display Width	232 mm
Display Height	140 mm
Display Depth	85 mm
Unit Weight	0.65 kg
Display Type	LCD alphanumeric
Display Lines	2 lines x 20 characters
Character Size	5 x 7 dot matrix
Membrane Keys	6 programmable
Communication Port	25-pin D-sub (RS-232/422)
Component Total	248 discrete parts
Internal Energy Storage	470 µF capacitor bank
Backlight Type	LED (yellow-green)
Backlight Life	50,000 hours typical
Operating Temperature	0°C to +50°C

Internal Design and Energy Storage

The 6ES5390-0UA11 contains exactly 248 discrete components inside. A 470 microfarad capacitor bank filters noise from the 24V DC power input. A dedicated microcontroller manages display and keypad functions. The module includes flash memory for storing configuration data. Six membrane switches provide tactile feedback for operator input. The LED backlight illuminates the LCD for clear visibility.

Operational Performance

This text display shows process variables and machine status in real time. It accepts operator inputs through six programmable membrane keys. Moreover, the unit communicates with the PLC via RS-232 or RS-422. You can configure display text and key functions using programming software. The module displays alarm messages and system diagnostics clearly. Four LEDs indicate power, communication, and alarm conditions. Consequently, you achieve local operator interface for S5 machine control. Siemens designed this display for industrial environments. Its rugged construction suits factory floor installation.

In summary, the 6ES5390-0UA11 delivers reliable text display functionality. Use this unit for machine status monitoring and operator input. It provides clear text display for S5 system diagnostics. Order this Simatic S5 text display for your Siemens automation system.
