Technical Overview
The 6AV4010-1AA10-0AB0 video module provides analog video signal processing for SIMATIC HMI systems. This module captures and displays camera feeds directly on compatible operator panels. It supports standard composite video inputs (PAL/NTSC) for monitoring industrial processes, machine vision, and security applications. The onboard video decoder converts analog signals into digital format for seamless integration.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Model Number | 6AV4010-1AA10-0AB0 |
| Product Type | Video Module |
| Series | SIMATIC HMI |
| Video Input | 1 x composite video (BNC connector) |
| Video Standards | PAL / NTSC (auto-detecting) |
| Resolution Support | Up to 768 x 576 pixels (PAL) / 720 x 480 (NTSC) |
| Digital Interface | Proprietary HMI bus |
| Power Supply | 5V DC via backplane |
| Dimensions (approx.) | 100mm x 40mm x 120mm |
| Approx. Weight | 0.25 kg |
| Operating Temperature | 0°C to +50°C |
| Status | Discontinued |
Video Signal Processing
The module accepts a standard composite video feed from any analog camera source. It converts the incoming signal into digital image data for display. The processor handles both PAL and NTSC formats automatically, simplifying integration with existing surveillance equipment.
System Integration and Display
This module connects directly to the HMI system’s internal bus for data exchange. It overlays video images onto operator screens for enhanced situational awareness. Engineers can configure display windows and positioning through the HMI software.
Industrial Applications
The 6AV4010-1AA10-0AB0 suits applications requiring live visual feedback, such as quality inspection and machine monitoring. Operators can view camera images alongside process data on a single panel. Consequently, this module reduces the need for separate display monitors in control rooms.
Installation and Cabinet Mounting
The compact design fits into standard HMI backplane slots. Users simply plug the module into an available slot and connect the camera cable. The BNC connector ensures a secure and reliable video signal connection.
