Siemens 6AV3535-1TA01-0AX0 Operator Panel

Technical Overview

The Siemens 6AV3535-1TA01-0AX0 is an operator panel designed for the SIMATIC S5 programmable controller series . This module serves as a human-machine interface (HMI), enabling operators to monitor and control industrial processes . It features a built-in monochrome display for visualizing process data and alarms . The panel includes a membrane keypad for operator input and system navigation . Its compact design fits easily into control cabinets and machine consoles.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Model Number	6AV3535-1TA01-0AX0
Product Type	Operator Panel
System Compatibility	SIMATIC S5
Display Type	Monochrome LCD
Keypad Type	Membrane
Communication Interface	Serial (RS-232/RS-485)
Power Supply	24 VDC
Operating Temperature	0°C to +50°C
Storage Temperature	-20°C to +70°C
Humidity	5% to 95% RH (non-condensing)
Protection Rating	IP40 (front panel)
Country of Origin	Germany

Key Features

Monochrome Display – The LCD screen shows process data, system status, and alarms clearly.

Membrane Keypad – The tactile keypad enables data entry and menu navigation.

S5 Compatibility – The panel integrates seamlessly with SIMATIC S5 controllers.

Compact Design – The small footprint saves valuable panel space.

Industrial-Grade Construction – The panel withstands demanding factory conditions.

Applications

The Siemens 6AV3535-1TA01-0AX0 suits machine-level control, process monitoring, and system diagnostics. It provides reliable HMI functionality for S5-based automation systems.Siemens 6AV3535-1TA01-0AX0 operator panel for SIMATIC S5, monochrome display, membrane keypad, 24V DC.
