Technical Overview
The Siemens 6AV3530-1RS32 is an operator panel belonging to the OP30/C series for the SIMATIC S5 programmable controller platform. This unit provides operators with a clear interface for monitoring process variables and controlling automation equipment. It features a monochrome display with contrast adjustment for optimal readability in various lighting conditions. The panel includes a membrane keypad for data entry and system navigation.
This HMI module connects to S5 controllers via serial communication ports, ensuring reliable data exchange. It operates on a 24 VDC power supply and draws minimal current. The robust construction withstands demanding industrial environments, ensuring long-term reliability. Its compact design fits easily into control cabinets and machine consoles. The panel supports multiple display formats for versatile application needs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Siemens |
| Model Number | 6AV3530-1RS32 |
| Product Type | Operator Panel / OP30/C |
| System Compatibility | SIMATIC S5 Series |
| Power Supply | 24 VDC |
| Protection Rating | IP40 (front panel) |
| Weight | Approx. 0.5 – 1.0 kg |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Certifications | CE, UL, CSA |
| Country of Origin | Germany |
Key Features
Clear Visual Feedback – The monochrome display presents process data and alarms in an easy-to-read format.
Intuitive Operator Interface – The membrane keypad enables straightforward data entry and menu navigation.
S5 System Compatibility – This panel integrates seamlessly with SIMATIC S5 controllers.
Robust Industrial Design – The rugged construction withstands vibrations, dust, and temperature variations.
Compact Footprint – The small panel size saves valuable space in control cabinets.
Applications
The Siemens 6AV3530-1RS32 suits machine-level control, process monitoring, and system diagnostics. It provides reliable HMI functionality for S5-based automation systems in manufacturing and process industries.
