Schneider TSXDSY08S5 Solid-State Discrete Output Module

Overview

The Schneider TSXDSY08S5 is a solid-state discrete output module designed for the Modicon Premium automation platform. This module delivers high performance with 8 discrete outputs, ensuring reliable control for industrial processes. It supports a wide voltage range of 48 to 240 VAC and provides efficient protection features like short-circuit, overload, and overvoltage protection.

Key Features

Manufacturer: Schneider Electric
Product Line: Modicon Premium
Part Number: TSXDSY08S5
Product Type: Solid-State Discrete Output Module
Range: Modicon Premium Automation Platform
Output Type: Triac Protected
Voltage Range: 48 to 240 VAC (conforming to EN/IEC 61131-2)
Output Number: 8 discrete outputs

Technical Specifications

Specification	Details
Part Number	TSXDSY08S5
Manufacturer	Schneider Electric
Product Line	Modicon Premium
Output Type	Triac Protected
Voltage Range	48–240 VAC
Current per Channel	2 A
Maximum Current per Module	12 A
Response Time	< 10 ms (activation), < 10 ms (deactivation)
Overvoltage Protection	Ge-Mov
Overload Protection	5 A, integrated fast blow fuse
Short-Circuit Protection	Yes
Insulation Resistance	> 10 MΩ at 500 V
Power Dissipation	0.5 V + 1 W × Number of Outputs × Current
Electrical Connection	Screw Terminal Block
Current Consumption	125 mA at 5 V DC
Module Format	Standard
Net Weight	0.34 kg

Product Description

The Schneider TSXDSY08S5 module is an integral part of the Modicon Premium automation platform, offering excellent reliability for industrial control systems. It features 8 discrete solid-state outputs, which are essential for precise control over industrial processes.

This module operates within a voltage range of 48 to 240 VAC, ensuring broad compatibility with various power supply configurations. The TSXDSY08S5 ensures high safety standards, equipped with overvoltage, overload, and short-circuit protection, thereby minimizing risk in harsh industrial environments.

With a response time of less than 10 ms for both activation and deactivation, this module delivers quick and efficient performance. Additionally, it includes an integrated fuse for overload protection and maintains high insulation resistance (>10 MΩ at 500 V), which enhances durability and reliability.

Applications

The TSXDSY08S5 module is ideal for industries requiring fast and reliable discrete output control. Its solid-state design ensures longevity and resilience, making it suitable for applications in automation, control systems, and industrial equipment where continuous, stable output is necessary.

This module works seamlessly with other components of the Modicon Premium automation platform, offering a versatile solution for various control tasks in industrial environments.
