GE IC200CHS002D: Box-Style I/O Carrier

This I/O carrier provides mounting and interconnection for VersaMax modules. It holds up two I/O modules and connects them to the network. The GE IC200CHS002D suits distributed control applications in harsh environments. You can install this carrier on a DIN rail or directly on a panel.

Technical Parameters Overview

Mechanical Construction and Layout

Furthermore, the GE IC200CHS002D features a rugged box-style enclosure. This enclosure uses high-impact polycarbonate material for durability. Two module bays sit side by side on the carrier surface. Each bay accepts one VersaMax I/O module of any type. The carrier provides physical alignment guides for easy insertion. Therefore, modules snap into place without any special tools.

Power Distribution and Bus Interface

This carrier distributes 24 VDC power to both installed modules. An internal bus carries data between modules and the network adapter. Two small capacitors store 360 µF of total energy. One 220 µF capacitor filters the incoming power supply. Another 140 µF capacitor stabilizes the communication bus voltage. Consequently, the GE IC200CHS002D delivers clean power even with fluctuating input.

Field Wiring and Termination Points

Two removable terminal blocks provide field wiring connections. One terminal block serves the left module slot. The second terminal block serves the right module slot. Each terminal block accommodates up to 20 field wires. The GE IC200CHS002D uses spring-clamp terminals for secure connections. You can replace a terminal block without disturbing existing wiring.

Component Population and Signal Routing

Moreover, 28 discrete components populate a single internal PCB. This board contains passive components and low-power logic circuits. Surface mount resistors and capacitors occupy minimal board space. The carrier includes no active processing components. Instead, it simply passes signals between modules and the backplane. The GE IC200CHS002D serves as a passive interconnect rather than an intelligent device.

Installation and Mounting Instructions

You can mount this carrier on a standard 35 mm DIN rail. Push the unit onto the rail until the latch clicks. Alternatively, secure the carrier directly to a panel using screws. Four mounting tabs accept M4 screws for panel installation. The GE IC200CHS002D operates in temperatures from -20°C to +60°C. It also withstands 5% to 95% non-condensing humidity.

System Configuration and Module Compatibility

This carrier works with all VersaMax I/O module families. You can install analog, digital, or specialty modules in either slot. Mix input and output modules freely within the same carrier. The network adapter determines the slot addressing scheme. The GE IC200CHS002D does not require any configuration or software setup. Simply insert modules and connect the field wiring to begin operation.
