ABB Bailey IMMFP03B Multi-Function Processor

This ABB Bailey IMMFP03B processor handles multiple control tasks simultaneously. It serves as the main computing unit for INFI 90 systems. The ABB Bailey IMMFP03B executes complex automation algorithms with high efficiency.

Technical Specifications

The ABB Bailey IMMFP03B measures 260 mm in length. Its width reaches 35 mm with a height of 190 mm. This multi-function processor weighs approximately 0.85 kilograms. A single multilayer PCB holds all processing and memory components.

Design and Energy Storage

This ABB Bailey IMMFP03B stores minimal energy in small backup capacitors. A battery retains system parameters during power loss. The processor executes control loops every 10 milliseconds. Surface-mount technology boosts reliability in industrial environments. Furthermore, the ABB Bailey IMMFP03B includes a watchdog timer for fault recovery.

Installation and Connectivity

You can mount this processor into any INFI 90 rack slot. It connects to the backplane via a 60-pin connector. Two serial ports allow communication with external devices. Consequently, you complete the installation within a few minutes. Finally, LED indicators show power, run, and fault status clearly.

Performance and Processing Power

This ABB consumes only 10 watts during operation. Its 25 MHz processor handles ladder logic and function blocks easily. Thus, you get reliable control for turbine and boiler applications. The onboard battery retains data for up to 30 days. The module also performs automatic self-checks every second.

Typical Applications

Use this ABB for steam turbine governor control. It also excels at boiler combustion management tasks. Many plants select it for burner management systems. The compact processor design saves valuable rack space effectively. Finally, remote configuration software simplifies programming significantly.
