Schneider DTA 102 High-speed Transport-Stream Output

High-Speed Data Output for Digital Broadcasting

The Schneider DTA 102 provides high-speed transport-stream output for digital video systems. This module transmits MPEG-2 and MPEG-4 data streams reliably. It suits broadcast headends, satellite uplinks, and cable television networks.

Technical Specifications

Parameter	Specification
Model	DTA 102
Category	High-speed Transport-Stream Output
Height	130 mm
Width	45 mm
Depth	200 mm
Weight	0.450 kg
Output Interfaces	2 x ASI (BNC, 75Ω), 1 x IP (RJ45)
ASI Data Rate	0 to 216 Mbps per port
IP Data Rate	0 to 500 Mbps (UDP/RTP)
Packet Size	188 or 204 bytes (programmable)
Output Impedance	75 Ω (ASI), 100 Ω (IP)
Return Loss	>15 dB at 270 MHz
Jitter	<5 ns peak-to-peak
Clock Source	Internal or external (TTL, 27 MHz)
Connector Type	2 x BNC, 1 x RJ45, 1 x BNC (clock input)
Status Indicators	4 x LEDs (PWR, LOCK, TX1, TX2)
Internal Components	1 FPGA, 2 ASI drivers, 1 Ethernet PHY, 1 oscillator
Energy Storage	47 µF filtering capacitor

Output Architecture and Data Transmission

The DTA 102 features two independent ASI output ports on BNC connectors. Each port transmits transport-stream data up to 216 Mbps. The module also includes one IP output for network streaming applications. An FPGA handles all data formatting and packet generation. The Schneider DTA 102 supports both 188-byte and 204-byte packet sizes. A 27 MHz crystal oscillator provides the master timing reference.

ASI Output Characteristics and Signal Quality

This high-speed transport-stream output provides 75 Ω impedance for ASI signals. The output return loss exceeds 15 dB at 270 MHz for minimal reflections. Peak-to-peak jitter measures less than 5 nanoseconds for stable decoding. The DTA 102 drives coaxial cables up to 300 meters without repeaters. It automatically detects and locks to the input clock source. Two green LEDs indicate active transmission on each ASI port.

IP Streaming and Network Integration

The Schneider DTA 102 includes a 100BASE-TX Ethernet port for IP output. This port supports UDP and RTP transport protocols. The module streams transport data at rates up to 500 Mbps. It accepts unicast or multicast destination addresses. You can configure the IP parameters through the management interface. The DTA 102 inserts time stamps for synchronized multi-device streaming.

Physical Dimensions and Installation Guidelines

The Schneider DTA 102 weighs 0.450 kilograms for straightforward rack mounting. Its height measures 130mm, width 45mm, and depth 200mm. Install this module in a standard 19-inch rack enclosure. The unit consumes 6.5 watts from the 12 V DC supply. It operates reliably from 0°C to +50°C ambient temperature. Use 75 Ω coaxial cable (RG59 or RG6) for ASI connections.

Energy Storage and Power Characteristics

The DTA 102 includes a 47 µF capacitor for power supply filtering. This capacitor stabilizes the internal voltage rails during load changes. The module requires an external 12 V DC power supply (not included). The Schneider DTA 102 contains no battery for configuration storage. It saves all settings in non-volatile flash memory permanently. You will never perform battery replacement on this transport-stream output module.
