Schneider ASB806124 | Output Module

The Schneider ASB806124 provides reliable discrete output control for the 800-Series system. This output module features 32 discrete output channels for high-density applications. It delivers 24 V DC sourcing outputs with 0.1 A per channel. Weighing only 0.48 kg, the Schneider ASB806124 mounts easily on a DIN rail or panel. Its dimensions measure 125 mm x 90 mm x 65 mm.

Output Specifications and Channel Features

The Schneider ASB806124 delivers 24 V DC sourcing (PNP) outputs for actuators and indicators. Each output channel provides 0.1 A (100 mA) of continuous current for small loads. The module groups outputs into four groups of eight channels for simplified wiring. Moreover, the Schneider ASB806124 includes built-in short-circuit protection on every output channel. Consequently, it protects itself and your field devices during fault conditions.

Protection Features and Energy Storage

The Schneider ASB806124 features over-temperature shutdown to prevent damage from overloads. This module also includes over-voltage protection for enhanced reliability in harsh environments. It contains no internal battery for complete maintenance-free operation. The Schneider ASB806124 draws 180 mA from the 5 V DC backplane power supply. Additionally, it consumes 400 mA from the external 24 V DC field power supply. Therefore, you never need to replace batteries or worry about data loss.

Technical Specifications Table

Below are the complete technical parameters for engineers and procurement teams:

Parameter	Specification
Full Product Name	Schneider ASB806124
Product Category	800-Series Discrete Output Module
Number of Output Channels	32
Output Type	Sourcing (PNP)
Rated Output Voltage	24 V DC (19.2 V to 30 V DC)
Output Current per Channel	0.1 A (100 mA)
Maximum Current per Group	0.8 A (8 channels x 0.1 A)
Maximum Current per Module	3.2 A total
Channel Grouping	4 groups of 8 channels
Protection Features	Short-circuit, over-temperature, over-voltage
Protection Reset	Automatic after fault removal
Output Response Time (ON)	< 0.5 ms
Output Response Time (OFF)	< 1.0 ms
Maximum Switching Frequency	500 Hz (resistive load)
Current Consumption (5V DC)	180 mA from backplane
Current Consumption (24V DC)	400 mA external field supply
Power Dissipation	3.8 W maximum
Energy Storage	No battery (decoupling capacitors only)
Number of Components	1 main PCB + 32 optocouplers + 2 terminal blocks + housing
Net Weight	0.48 kg (480 grams)
Gross Weight (packaged)	630 grams
Dimensions (H x W x D)	125 mm x 90 mm x 65 mm
Wire Size (Terminal)	AWG 24 to AWG 14 (0.2 mm² to 2.5 mm²)
LED Indicators	32 (green, one per channel) + power LED
Operating Temperature	0°C to +55°C
Storage Temperature	-40°C to +85°C
Degree of Protection	IP20
Certifications	CE, UL 508, CSA

Connector and Installation Details

The Schneider ASB806124 uses two removable screw terminal blocks for all field wiring. One terminal block handles outputs 1 through 16 and their common connections. The second terminal block manages outputs 17 through 32 and the power supply. The module requires an external 24 V DC power supply for output operation. Therefore, do not rely solely on backplane power for field devices. The Schneider ASB806124 suits LED indicators, small relays, solenoid valves, and contactors. It works perfectly for packaging machines, conveyors, and material handling systems. Thus, this output module delivers dense discrete control for space-constrained industrial cabinets.
