Schneider 170INT11003 Communication Adapter

Overview

The Schneider 170INT11003 is an advanced communication adapter in the Modicon Momentum series, designed to seamlessly integrate devices within industrial automation systems. It operates with a Master/Slave configuration and supports the Interbus Generation SUPI III protocol for efficient and reliable communication. This adapter enables the connection of up to 254 devices per segment, making it an ideal solution for large-scale control networks.

Key Features

• Communication Protocol: The 170INT11003 supports Interbus Generation SUPI III, ensuring high-speed and reliable communication between devices.
• Number of Devices: It supports up to 254 devices per segment, offering flexibility in complex systems.
• Access Method: Features both Master/Slave and Continuous Shift Register modes for seamless data transfer.
• Transmission Rate: Achieves a transmission rate of 500 kilobits per second, providing fast and efficient data handling.
• Network Topology: Utilizes a Ring Network topology, ensuring robustness and fault tolerance in communication.
• Maximum Cable Distance:
  • Between devices: 1,000 meters (3,280 feet).
  • Between two modules: 400 meters (1,312 feet).
• Power Consumption: The device operates with a low power dissipation of 0.8 watts, making it energy efficient.

Technical Specifications

Description

The Schneider 170INT11003 adapter is built to handle large industrial communication networks with ease. It supports Master/Slave configuration and ensures smooth data transmission with Continuous Shift Register access. With the ability to link up to 254 devices per segment, this adapter is highly scalable for extensive automation networks.

Operating on the Interbus Generation SUPI III protocol, the 170INT11003 offers exceptional communication reliability, even in demanding environments. The device can manage a maximum cable length of 1,000 meters (3,280 feet) between devices, and 400 meters (1,312 feet) between two modules, ensuring flexibility in system design.

The adapter operates with a low power dissipation of 0.8 watts, promoting energy efficiency. Its 500 kilobits per second transmission rate enables fast data transfer, which is crucial for real-time industrial applications. The IP20 protection class ensures basic protection against solid foreign objects.

This device performs reliably within an ambient temperature range of 0°C to 60°C and can endure high altitudes of up to 5,000 meters (16,404 feet). It connects via two 9-pin D-Sub connectors, ensuring strong and stable communication links. Additionally, the Schneider 170INT11003 adapter can be stored in temperatures ranging from -40°C to 85°C.

To ensure data integrity, the device uses CRC-16 for control parameter verification. The ring network topology allows for continuous data flow and reduces the risk of communication failures. Finally, the use of twisted pair cables enhances the electromagnetic compatibility (EMC), minimizing interference.

Applications

• Industrial Automation Networks: Ideal for creating large, scalable networks that require high reliability.
• Factory Control Systems: Supports the connection of multiple devices, such as sensors, controllers, and actuators.
• Remote Monitoring: Perfect for networks requiring long cable distances between devices while maintaining real-time communication.
• Data Acquisition: Enables fast and accurate data transfer in industrial settings where speed is critical.

Conclusion

The Schneider 170INT11003 communication adapter is designed to optimize industrial communication networks. With its flexible device connections, high transmission rate, and robust features, it offers the performance and reliability needed for modern automation systems. Whether for Modicon Momentum series applications or larger industrial networks, this adapter ensures smooth, efficient communication in demanding environments.
